| Ref | Part Number | Description |
|---|
| 1 |
515177509 |
LH Switch Housing This part replaces 515177020. |
| 2 |
515176088 |
Start/RER Button |
| 3 |
515175926 |
Housing Switch Plate |
| 4 |
250000263 |
Torx Screw #8-18 |
| 5 |
515177362 |
Kill Switch This part replaces 515177061. |
| 6 |
515175768 |
MALE TERMINAL - Call your local BRP dealership |
| 7 |
515177310 |
Emergency Stop Switch Support This part replaces 515176825. |
| 8 |
250000263 |
Torx Screw #8-18 |
| 9 |
515176868 |
STEERING WIRING HARNESS ASS'Y - Call your local BRP dealership |
| 10 |
515175662 |
Male Terminal Housing, 6 Circuits |
| 11 |
515175846 |
Male Terminal Housing, 4 Circuits |
| 12 |
506152428 |
Heated Film, 25W |
| 13 |
515175232 |
Male Terminal |
| 14 |
293550004 |
Dielectric Grease, 150 g |
