| Ref | Part Number | Description |
|---|
| 2 |
0301967 |
O RING |
| 5 |
0318626 |
BILLE |
| 6 |
0391849 |
ROULEMENT À BILLES |
| 23 |
0193195 |
PLUG, Filter |
| 31 |
0306503 |
SCREW, Short |
| 32 |
0309484 |
SCREW |
| 38 |
0325115 |
SCREW, Oil tank/EMM mount |
| 51 |
0985331 |
HOSE Pump assy. to engine cover, pressure |
| 54 |
0913332 |
CLAMP, Hose to air silencer |
| 55 |
0913333 |
GROMMET, Oil line |
| 58 |
0912112 |
RETAINING RING |
| 61 |
0985055 |
SHAFT |
| 63 |
0984372 |
BEARING, Lower |
| 64 |
0304612 |
RETAINING RING |
| 65 |
0912463 |
SPACER |
| 71 |
0912152 |
HOSE, Control valve to adapter |
| 72 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 74 |
0330366 |
HOSE, Control valve to cover |
| 77 |
0912064 |
SLEEVE, Oil cooler |
| 78 |
0912000 |
ELBOW, Oil cooler |
| 83 |
0912226 |
GROMMET, Return tube |
| 84 |
0331887 |
HOSE, Overboard |
| 0985328 |
0436214 |
PUMP MOUNTING KIT This part replaces 0985328. |
