| Ref | Part Number | Description |
|---|
| 3 |
0332537 |
LATCH HANDLE & SHAFT ASSEMBLY |
| 4 |
0330253 |
HOOK Front |
| 8 |
0434172 |
ENGINE COVER, Lower This part replaces 0330918. |
| 9 |
0317290 |
BRACKET, Port, rear |
| 10 |
0317291 |
BRACKET, Starboard, rear |
| 10 |
504154289 |
Deep Black, Chain Case Ass'y |
| 12 |
0313839 |
BRACKET, Cover, port |
| 13 |
0313840 |
BRACKET, Cover, starboard |
| 14 |
0321885 |
NIPPLE |
| 15 |
0329240 |
SCREW |
| 17 |
0329241 |
RONDELLE |
| 18 |
0316354 |
ENGINE COVER SUPPORT GROMMET |
| 19 |
0302406 |
SLEEVE |
| 20 |
0304027 |
VIS, arbre de commande de sens de marche This part replaces 0330154. |
| 20 |
250001213 |
Socket Head Screw M6 X 18 |
| 21 |
0333739 |
RETAINER, Fuel hose to cover This part replaces 0329610. |
| 22 |
0310539 |
SCREW, Clamp choke solenoid |
| 23 |
0398229 |
BODY AY This part replaces 0395543. |
| 24 |
0328731 |
VIS, câble de verrouillage This part replaces 0329265. |
| 25 |
0331533 |
JOINT, conn. carburant vers capot inférieur |
| 26 |
0384338 |
HANDLE & SHAFT ASSY. |
| 31 |
0318401 |
GROMMET, Remote cont cable |
| 32 |
0206268 |
SPRING, Handle detent |
| 70 |
250001016 |
Hex Flanged Screw M8 X 25 S.Grip |
| 80 |
233261434 |
Flanged Elastic Nut M6 |
| 100 |
293200168 |
Oil Seal |
| 110 |
293350153 |
Ball Bearing |
| 120 |
504152576 |
Circlip |
| 130 |
504152628 |
Shim |
| 140 |
504153911 |
Sprocket 23 Teeth |
| 150b |
293350142 |
Ball Bearing |
| 150c2 |
504154043 |
Cap |
| 150d |
293300291 |
O-Ring Seal This part replaces 293300230. |
| 280 |
504152784 |
Spring Washer M10 |
| 290 |
207503046 |
Hex. Flange Screw M10 X 30, Scotch Grip |
| 1100 |
293200159 |
Oil Seal |
| 1120 |
504152582 |
Circlip |
| 1130 |
504153996 |
Sprocket 49 Teeth |
| 1140 |
504152572 |
Circlip |
| 1500 |
504153397 |
Drive Chain, 116 Links |
| 1510 |
414575600 |
Hair Pin |
| 1520 |
504153760 |
Adjustment Screw |
| 1540 |
250500013 |
Hex. Countersunk Drain Plug |
| 1545 |
250500013 |
Hex. Countersunk Drain Plug |
| 1550 |
293300202 |
O-Ring |
| 1600 |
504154577 |
Chain Tensioner |
| 1610 |
504153312 |
Chain Slider |
| 1650 |
293370105 |
Circlip |
| 1690 |
250000764 |
Hex. Button Head Screw M8 X 1.25 X 35 |
| 1700d |
515179692 |
Clip Connector |
| 1700f |
415130141 |
Sleeve |
| 1710 |
293300200 |
O-Ring |
| 1720 |
250001153 |
Flanged Hex. Screw M6X20 |
| 1740a |
504152930 |
Cap This part replaces 504154304. |
| 1740b |
293710180 |
Straight Pipe Fitting |
| 1740c |
219704539 |
Hose 5.7MM - 630MM |
| 1790 |
250001015 |
Flanged Hex. Screw M6 X 35 |
| 2030 |
293300201 |
O-Ring |
| 2040 |
504154043 |
Cap |
| 2050 |
504152572 |
Circlip |
| 2500b |
250300028 |
Clinch Stud, M8 X 25 |
| 2510 |
233281414 |
Hex. Flange Elastic Nut M8 |
| 3000b |
XXX |
Not Available As Spare Parts |
| 3000c |
XXX |
Not Available As Spare Parts |
| 3000d |
504154417 |
Retaining Ring |
| 3000f |
293350059 |
Ball Bearing |
| 3000g |
293300291 |
O-Ring Seal This part replaces 293300230. |
| 3200a |
415130661 |
Clip |
| 3200b |
504152651 |
Cleat |
| 4000 |
250000764 |
Hex. Button Head Screw M8 X 1.25 X 35 |
