| Ref | Part Number | Description |
|---|
| 1 |
0911316 |
RETAINING RING |
| 2 |
0908461 |
GEAR, Shaft |
| 3 |
0908865 |
WASHER |
| 4 |
0910292 |
BUSHING, Actuator bracket |
| 6 |
0909943 |
STEERING SHAFT |
| 7 |
0908060 |
BOW WASHER, Shoulder screw |
| 8 |
0909974 |
SPACER |
| 9 |
0305296 |
COTTER PIN |
| 10 |
0300721 |
WASHER, Cable connector |
| 11 |
0321232 |
RETAINER WASHER |
| 12 |
3852474 |
SCREW, Mount to bracket This part replaces 0909682. |
| 13 |
0909919 |
SCREW, Cover |
| 14 |
0909920 |
THRUST WASHER |
| 15 |
0909921 |
THRUST WASHER |
| 16 |
0909923 |
GEAR |
| 17 |
0909925 |
CLUSTER GEAR |
| 18 |
0909926 |
THRUST WASHER |
| 19 |
0909927 |
SHAFT, Input gear |
| 20 |
0982256 |
OUTPUT GEAR & COLLAR ASSY |
| 22 |
3852420 |
LOCKNUT, Throttle lever This part replaces 0900402. |
| 23 |
3852478 |
SCREW, Prop shaft retainer This part replaces 0909937. |
| 24 |
0910050 |
BRACKET, Gearbox to has |
| 25 |
0909993 |
BALL SEAL |
| 26 |
0910081 |
WASHER |
| 27 |
0910082 |
SPRING |
| 28 |
0910083 |
WASHER, Friction |
| 29 |
0303398 |
VIS, support This part replaces 0302030. |
| 30 |
0983400 |
HUB & TILLER ARM ASSY |
| 31 |
0982392 |
COVER & HOUSING - BRG. ASS'Y |
| 32 |
0983317 |
BEARING & CARRIER ASSY |
| 33 |
0909991 |
BEARING |
| 34 |
0909990 |
BEARIG,Cluster gear,cover & housing |
| 35 |
0909929 |
BEARING, Input |
| 36 |
0909928 |
BEARING, Tiller arm to cover |
| 37 |
0909930 |
SEAL, Tiller arm |
| 38 |
0300721 |
WASHER, Cable connector |
| 39 |
0909941 |
BRACKET, Cylinder to hsg |
| 40 |
0910880 |
BRACKET, Actuator to hsg |
| 41 |
0909970 |
SCREW, Bracket to hsg |
| 42 |
3852496 |
LOCK WASHER, Bracket to pump This part replaces 0910320. |
| 43 |
0120177 |
L'WASHER, Alternator to brkt |
| 44 |
0910324 |
SCREW |
| 46 |
3857014 |
BRACKET, Power steering This part replaces 0910841. |
| 47 |
3853402 |
STUD, Bracket to engine This part replaces 0910527. |
| 48 |
3850491 |
Pump Ay This part replaces 0983791. |
| 49 |
3852497 |
O-RING, Pressure hose This part replaces 0910321. |
| 50 |
0303293 |
LKWASH,Cylinder & clevis,actuator,bracket |
| 51 |
3852434 |
CLAMP, Engine cable This part replaces 0908191. |
| 52 |
0910287 |
DRAG LING, Tiller arm to cable |
| 53 |
0909933 |
NUT, Tube to valve |
| 54 |
0316954 |
LOCKWASHER |
| 55 |
0911569 |
TUBE GUIDE, Valve |
| 56 |
0910027 |
NUT, Steering tube |
| 57 |
0910286 |
TUBE, Steering cable guide |
| 58 |
0317943 |
NUT |
| 59 |
3852464 |
BELT, Alternator This part replaces 0908929. |
| 60 |
0979803 |
CLAMP |
| 62 |
3853804 |
PULLEY, Steering pump This part replaces 0983734. |
| 63 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 65 |
0909975 |
HOSE, Hsg to oil cooler |
| 66 |
0986045 |
HOSE, Valve to cooler This part replaces 0909979. |
| 67 |
0982577 |
HOSE, Pump to actuator pressure |
| 68 |
0306995 |
L'WASHER,Nut,tube guide to valve |
| 70 |
0301988 |
NUT |
| 71 |
0983735 |
CYL & CLEVIS ASSY |
| 73 |
0308335 |
CLAMP, Coil |
| 74 |
3853236 |
SLEEVE, Ignition coil This part replaces 0308716. |
| 75 |
3852218 |
BRACKET, Oil cooler This part replaces 0383448. |
| 76 |
0174177 |
ELBOW KIT This part replaces 0909985. |
| 77 |
0983849 |
OIL COOLER This part replaces 0983720. |
| 78 |
0909251 |
PLUG, Cooler |
| 79 |
3852478 |
SCREW, Prop shaft retainer This part replaces 0909937. |
| 80 |
0909934 |
ADAPTER, Valve mounting |
| 81 |
0983732 |
ACTUATOR & VALVE ASSY |
| 83 |
0982231 |
LINE ASSY CYL TO VALVE |
| 84 |
0310896 |
SCREW |
| 85 |
0910879 |
SCREW, Bracket to housing |
| 87 |
3759755 |
STUB, Water pump, lower (RH) |
| 88 |
0305486 |
WASHER |
