| Ref | Part Number | Description |
|---|
| 3 |
0328009 |
TILT HANDLE This part replaces 0330013. |
| 4 |
0210421 |
SEAL, Engine cover |
| 5 |
0329762 |
LOCATING BRACKET, Front |
| 6 |
0394976 |
LOCATING BRACKET, Rear |
| 8 |
0210644 |
LIFT HANDLE |
| 9 |
0210415 |
APPLIQUE, Port & stbd |
| 11 |
0210411 |
APPLIQUE, Rear & front |
| 12 |
0334004 |
SCREW, Hook to bracket |
| 13 |
0210505 |
APPLIQUE, Front |
| 18 |
0330012 |
BAFFLE |
| 19 |
0328608 |
BRACKET, Louver mounting., 300 |
| 20 |
0397630 |
HOOK |
| 21 |
0210771 |
PLATE, Applique, front |
| 22 |
0210475 |
LOUVER, Port |
| 23 |
0210474 |
LOUVER, Starboard |
| 0283110 |
0283242 |
ENGINE COVER ASSY., This part replaces 0283110. |
| 0283210 |
0283210 |
ENGINE COVER ASSY. |
| 0283356 |
0283356 |
DECAL SET |
