| Ref | Part Number | Description |
|---|
| 1010 |
250000712 |
Torx Screw M6 X 20 |
| 1200 |
705011331 |
LH Rocker Panel |
| 1210 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250000957. |
| 1220 |
293150101 |
Pop Rivet 3/16” This part replaces 293150101. |
| 1230 |
250000867 |
Torx Truss Hex. Screw M6X35, Nylon Patch |
| 1240 |
250000840 |
Torx Truss Screw Head PT.K50 X 40 |
| 1250 |
250200162 |
Flat Washer M6.6 X 22 |
| 1300 |
705016939 |
RH Front Rocker Panel This part replaces 705011332. |
| 1415 |
207662554 |
Hex. Flange Screw M6 X 25 |
| 2720 |
234062670 |
Stainless Steel Flat Washer |
| 2730 |
250000722 |
Torx Screw M6 X 20 |
| 2800 |
705014696 |
Front Skid Plate |
| 2810 |
293150087 |
Pop Rivet 3/16” This part replaces 293150087. |
| 2820 |
293150087 |
Pop Rivet 3/16” This part replaces 293150087. |
| 2830 |
250200191 |
Washer |
| 2900 |
705011428 |
Central Skid Plate |
| 2910 |
293150087 |
Pop Rivet 3/16” This part replaces 293150087. |
| 2920 |
293150087 |
Pop Rivet 3/16” This part replaces 293150087. |
| 3000 |
705014697 |
Rear Skid Plate |
| 3010 |
293150087 |
Pop Rivet 3/16” This part replaces 293150087. |
| 3020 |
250200191 |
Washer |
| 3100 |
705011430 |
LH Median Side Panel |
| 3110 |
250000722 |
Torx Screw M6 X 20 |
| 3200 |
705011431 |
RH Median Side Panel |
| 3300 |
705013190 |
LH Rear Rocker Panel |
| 3310 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250000957. |
| 3320 |
293150108 |
Pop Rivet 3/16” This part replaces 293150108. |
| 3330 |
250000867 |
Torx Truss Hex. Screw M6X35, Nylon Patch |
| 3340 |
250000840 |
Torx Truss Screw Head PT.K50 X 40 |
| 3350 |
250200162 |
Flat Washer M6.6 X 22 |
| 3400 |
705013191 |
RH Rear Rocker Panel |
| 3810 |
250000840 |
Torx Truss Screw Head PT.K50 X 40 |
