| Ref | Part Number | Description |
|---|
| 800 |
715007481 |
Median Deflector Kit This part replaces 715003774. |
| 805 |
707900469 |
Plate |
| 806 |
293150230 |
Tuflok Plastic Rivet This part replaces 293150089. |
| 810 |
293150230 |
Tuflok Plastic Rivet This part replaces 293150089. |
| 815 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250000957. |
| 830 |
707900994 |
LH Lower Panel This part replaces 707900443. |
| 835 |
293150230 |
Tuflok Plastic Rivet This part replaces 293150089. |
| 836 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250000957. |
| 840 |
707900444 |
RH Lower Cover |
| 845 |
293150230 |
Tuflok Plastic Rivet This part replaces 293150089. |
| 846 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250000957. |
| 1800a |
293830005 |
Rubber Bumper |
| 1800b |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250000957. |
| 1810 |
293150230 |
Tuflok Plastic Rivet This part replaces 293150089. |
| 2000 |
707900326 |
Engine Service Cover |
| 2010 |
293150230 |
Tuflok Plastic Rivet This part replaces 293150089. |
| 2100 |
707900419 |
Support belt cover |
| 2730 |
250100199 |
Insert Half Hex Body M6 x 1.0 |
| 3400 |
715003314 |
Storage Box |
| 3420 |
269501945 |
Clip |
| 3430 |
293250453 |
Neoprene Seal |
| 3440 |
293830005 |
Rubber Bumper |
| 3800 |
707900996 |
Rear Panel This part replaces 707900426. |
| 3810 |
293150230 |
Tuflok Plastic Rivet This part replaces 293150089. |
| 3820 |
250200162 |
Flat Washer M6.6 X 22 |
| 3830 |
250000722 |
Torx Screw M6 X 20 |
| 3840 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250000957. |
| 4000 |
707900228 |
Rear Lower Bulkhead |
| 4005 |
705005156 |
Oval Washer |
| 4010 |
293150230 |
Tuflok Plastic Rivet This part replaces 293150089. |
| 4015 |
503192494 |
Washer |
| 4040 |
250000722 |
Torx Screw M6 X 20 |
| 4050 |
234062670 |
Stainless Steel Flat Washer |
| 4060 |
250100199 |
Insert Half Hex Body M6 x 1.0 |
| 4070 |
250000954 |
Torx Screw M6 X 70 |
| 4080 |
250200162 |
Flat Washer M6.6 X 22 |
| 4090 |
250000722 |
Torx Screw M6 X 20 |
| 4100 |
707900282 |
Battery Cover |
| 5020 |
293150230 |
Tuflok Plastic Rivet This part replaces 293150089. |
| 5030 |
292001663 |
Flat Washer 8 mm, Nylon |
