08- Rear Shocks
Parts (10)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 503189292 | Front Arm |
| 3 | 503189388 | Rocker Axle |
| 4 | 503189626 | CUSHION - Call your local BRP dealership |
| 5 | 207005044 | Hex. Screw M10 X 1.5 X 50 |
| 6 | 233601416 | Elastic Locking Nut M10 X 1.5 |
| 14 | 207684044 | Hex. Flange Screw M8 X 40 |
| 15 | 233281414 | Hex. Flange Elastic Nut M8 |
| 16 | 414936000 | Bushing |
| 17 | 408200700 | Grease Fitting |
| 18 | 219700417 | SYNTHETIC GREASE, 400 G - Call your local BRP dealership |
