| Ref | Part Number | Description |
|---|
| B |
Not |
Available As Spare Part - Loctite 243, 10 ml |
| N |
Not |
Available As Spare Part - Multipurpose Grease BP LS3 |
| O |
Not |
Available As Spare Part - Engine Oil |
| P |
Not |
Available As Spare Part - Loctite 5910 |
| 2 |
420632010 |
Center Pin 8 X 12 |
| 3 |
420641323 |
Plug Screw M10 X 1 |
| 4 |
420840500 |
Threaded Pin |
| 5 |
420933180 |
Cushion |
| 6 |
420933185 |
Cushion |
| 7 |
420933140 |
Ring Half |
| 8 |
420832232 |
Ball Bearing |
| 10 |
420845790 |
Retaining Ring |
| 12 |
420440852 |
Torx Flange Screw M8 X 16 |
| 13 |
420641213 |
Torx Flange Screw M8 X 55 |
| 14 |
420440274 |
Torx Flange Screw M6 X 35 |
| 15 |
420940945 |
Torx Flange Screw M9 X 113 |
| 16 |
420911124 |
Oil Sump This part replaces 420911122. |
| 18 |
420841549 |
Torx Flange Screw M6 X 25 |
| 20 |
420686024 |
Gasket Set Engine 602 This part replaces 420686022. |
