| Ref | Part Number | Description |
|---|
| 7 |
0344212 |
CLAMP, Grommet, fuel lines |
| 8 |
0344208 |
FLOAT HINGE PIN |
| 9 |
0343938 |
SLEEVE, Fuel pump |
| 10 |
HOSE, |
Tube to filter inlet, 12 1/2 in. (318 mm) |
| 11 |
0343934 |
NIPPLE, Fuel outlet |
| 12 |
0915882 |
GASKET, Float needle seat |
| 13 |
0344209 |
SEAT, Float needle |
| 14 |
HOSE, |
Water, reservoir to tee,40 in. (1016mm) |
| 15 |
0510487 |
RETAINING RING |
| 16 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 17 |
HOSE, |
Inlet tube to lift pump, 10 in. (254mm) |
| 18 |
HOSE, |
Vapor sep. to port intake manifold nipp e, 12 in. (305mm) |
| 19 |
0915957 |
SCREW, Cover |
| 21 |
0343915 |
GASKET, Water cover |
| 23 |
0915957 |
SCREW, Cover |
| 24 |
0915880 |
FLOAT |
| 25 |
0344235 |
GROMMET, Fuel tubes |
| 26 |
0344578 |
HOSE, Tube to vapor separator |
| 27 |
0343942 |
HOSE, Lift pump outlet to tube |
| 28 |
0439172 |
TUBE & HOSE ASSY., Injector return to pressur regulator |
| 30 |
0345613 |
HOSE, Pulse nipple to lift pump, lower |
| 31 |
0333635 |
HOSE, Filter to fuel manifold |
| 32 |
0916017 |
O-RING, Elbow |
| 33 |
0343898 |
SHIELD, Fuel filter |
| 35 |
0439893 |
NIPPLE ASSY. |
| 38 |
0335230 |
O-RING |
| 39 |
3853620 |
SCREW, Circuit breaker This part replaces 0915982. |
| 40 |
0343926 |
BRACKET, Vapor separator |
| 41 |
0343918 |
GASKET, Vapor separator cover |
| 42 |
0343935 |
CLAMP, Fuel pump |
| 43 |
0915884 |
CLIP, Needle to float |
| 44 |
0343903 |
NIPPLE, Mount, pulse hose & fuel bracket, por |
| 45 |
0334131 |
FLEXIBLE, impulsions |
| 46 |
0439572 |
COVER ASSY., Vapor separator |
| 49 |
0343946 |
HOSE, Blow off valve to head, Port |
| 50 |
0343914 |
COVER, Water chamber |
| 51 |
0343909 |
ELBOW, Fuel reservoir |
| 52 |
5000334 |
FUEL PUMP, High pressure |
| 53 |
5000336 |
NIPPLE & O-RING KIT, Fuel pump |
| 54 |
0916017 |
O-RING, Elbow |
| 55 |
0915883 |
NEEDLE, Float |
| 56 |
0438934 |
FUEL RESERVOIR |
| 57 |
0343904 |
NIPPLE, Mount, starboard |
| 58 |
0343765 |
COLLIER, flexible d'indicateur d’éjection |
| 59 |
0439849 |
LIFT PUMP ASSY. |
| 60 |
0335200 |
VIS, capteur position de vilebrequin vers support |
| 61 |
0438622 |
FUEL FILTER ASSY. |
| 63 |
0438645 |
FILTER |
| 64 |
3853598 |
ELBOW, Hose to reservoir This part replaces 0915946. |
| 65 |
0438644 |
SENSOR ASSY. |
| 66 |
0343765 |
COLLIER, flexible d'indicateur d’éjection |
| 67 |
0439171 |
TUBE & HOSE ASSY., Fuel pump to injectors |
| 68 |
0344238 |
TUBE, Lift pump to filter, inlet |
| 69 |
0344239 |
TUBE, Filter outlet to vapor sep. |
| 70 |
0438816 |
REPAIR KIT, Fuel pressure regulator (Includes #38) |
| 71 |
0439849 |
LIFT PUMP ASSY. This part replaces 0438815. |
