| Ref | Part Number | Description |
|---|
| 20 |
293150230 |
Tuflok Plastic Rivet |
| 50 |
705005162 |
Bumper Cap This part replaces 705007104. |
| 180 |
250000759 |
Torx Truss Pt K40 X 16 |
| 190 |
293150230 |
Tuflok Plastic Rivet |
| 200 |
705007067 |
LH Front Deflector |
| 210 |
705007068 |
RH Front Deflector |
| 220 |
250000722 |
Torx Screw M6 X 20 |
| 225 |
250100198 |
Panel Nut M6 X 1.0 |
| 230 |
705007305 |
Front Wing Moulding LH |
| 240 |
705007306 |
Front Wing Moulding RH |
| 320 |
705006824 |
Néoprene Pad |
| 330 |
219704371 |
Neoprene Seal 3000 mm Long |
| 440 |
705003248 |
Hood Arm |
| 450 |
207561244 |
Hex. Flange Screw M6 X 12, Scotch Grip |
| 460 |
705005434 |
Hood Pivot |
| 470 |
705003322 |
Spacer |
| 480 |
230061034 |
Hex. Screw M6 X 110 |
| 490 |
233261434 |
Flange Elastic Nut M6 |
| 500 |
250000712 |
Torx Screw M6 X 20 |
| 510 |
269500252 |
M6 Nut Housing Ass'y |
| 590 |
705004579 |
Lower Air Duct LH |
| 600 |
705004580 |
Lower Air Duct RH |
| 610 |
705005859 |
Rear Air Duct LH |
| 620 |
705005860 |
Rear Air Duct, RH |
| 630 |
705008132 |
Radiator Grille |
| 640 |
250000722 |
Torx Screw M6 X 20 |
| 650 |
250100198 |
Panel Nut M6 X 1.0 |
| 670 |
293150230 |
Tuflok Plastic Rivet |
| 680 |
250000712 |
Torx Screw M6 X 20 |
| 690 |
269500252 |
M6 Nut Housing Ass'y |
| 800a |
293740028 |
Dual Lock Velcro Washer 3/4" |
| 800b |
390401400 |
Rivet |
| 800c |
234031600 |
Flat Washer 3 mm, Stainless Steel |
| 810 |
705011444 |
Fuse Cover Ass'y |
| 820a |
293740028 |
Dual Lock Velcro Washer 3/4" |
| 830 |
250000767 |
Torx Truss Screw M6 X 12 |
| 870 |
234461608 |
External Serrated Lock Washer 6 mm |
| 880a |
235564054 |
Screw-torx Button Head M6 X 40 |
| 890 |
233261494 |
Hex. Flange Elastic Nut M6 |
| 920 |
705004513 |
Bushing |
| 930 |
705004468 |
Hood Guide |
| 940 |
250000720 |
Torx Screw K50 X 16 |
| 970 |
517305460 |
Hood Cable |
| 980 |
710002896 |
Tie-Rap Clip |
| 1020 |
293830005 |
Rubber Bumper |
| 1030 |
705002837 |
Skid Plate |
| 1035 |
250000760 |
Torx Screw Truss Head K50X20 T20 |
| 1040 |
250000728 |
Torx Screw M6 X 25 |
| 1050 |
250100198 |
Panel Nut M6 X 1.0 |
| 1060 |
250000728 |
Torx Screw M6 X 25 |
| 1070 |
250100198 |
Panel Nut M6 X 1.0 |
| 1150 |
269500252 |
M6 Nut Housing Ass'y |
| 1280 |
708200636 |
Vegas White Pearl, LH Front Panel |
| 1280 |
708200706 |
Asphalt Gray, LH Front Panel |
| 1280 |
708200766 |
Oxford Blue Metallic, LH Front Panel |
| 1280 |
708200848 |
Front Panel LH, Phoenix Orange B-424 |
| 1290 |
708200637 |
Vegas White Pearl, RH Front Panel |
| 1290 |
708200707 |
Asphalt Gray, RH Front Panel |
| 1290 |
708200768 |
Oxford Blue Metallic, RH Front Panel |
| 1290 |
708200849 |
Front Panel RH, Phoenix Orange B-424 |
| 1320 |
293150230 |
Tuflok Plastic Rivet |
| 1360 |
207662044 |
Hex. Flange Screw M6 X 20 |
| 1370 |
250100198 |
Panel Nut M6 X 1.0 |
| 5655 |
708000759 |
Rubber Stopper |
| 7530 |
705002839 |
Service Center Access Panel LH |
