| Ref | Part Number | Description |
|---|
| 1 |
219904010 |
WARNING DECAL - Call your local BRP dealership |
| 3 |
219904018 |
SEA-DOO DECAL - Call your local BRP dealership |
| 5 |
262000042 |
WHEEL FENDER, GREY - Call your local BRP dealership |
| 5 |
262000242 |
WHEEL FENDER, BLACK - Call your local BRP dealership |
| 6 |
262000044 |
COUPLER - Call your local BRP dealership |
| 7 |
262000045 |
SAFETY CABLE - Call your local BRP dealership |
| 8 |
262000050 |
PROTECTOR - Call your local BRP dealership |
| 9 |
262000216 |
BUNK BRACKET - Call your local BRP dealership |
| 10 |
262000217 |
BUNK ASS'Y - Call your local BRP dealership |
| 15 |
269800305 |
HEX. CAP SCREW 3/8 -16 X 1 - Call your local BRP dealership This part replaces 269800005. |
| 16 |
269800178 |
WINCH SUPPORT, BLACK - Call your local BRP dealership |
| 16 |
269800677 |
ADJUSTABLE WINCH SUPPORT GALVANIZED - Call your local BRP dealership This part replaces 269800074. |
| 17 |
269800076 |
MOUNT CHANNEL SUPPORT, GALV - Call your local BRP dealership |
| 17 |
269801298 |
SUPPORT_WINCH PAINTED - Call your local BRP dealership This part replaces 269800177. |
| 18 |
269800078 |
WINCH - Call your local BRP dealership |
| 19 |
269800317 |
HEX. BOLT 3/8''-16 X 4 1/2'' - Call your local BRP dealership |
| 20 |
269800401 |
HEX. BOLT 1/2''-13 X 4'' - Call your local BRP dealership This part replaces 269800131. |
| 20 |
291003301 |
HEX. CAP BOLT 3/8''-16 X 4'' - Call your local BRP dealership |
| 21 |
269800132 |
HEXAGONAL BOLT - Call your local BRP dealership |
| 21 |
269800305 |
HEX. CAP SCREW 3/8 -16 X 1 - Call your local BRP dealership |
| 22 |
269800307 |
HEX. BOLT 1/2'' - 13 X 4 1/2'' - Call your local BRP dealership This part replaces 269800134. |
| 23 |
269800136 |
SCREW - Call your local BRP dealership |
| 24 |
269800308 |
HEX. BOLT 1/2''-13 X 1-1/4'' - Call your local BRP dealership This part replaces 269800137. |
| 25 |
269800309 |
WASHER 1/2'' - Call your local BRP dealership This part replaces 269800139. |
| 26 |
269800300 |
FLAT WASHER - Call your local BRP dealership |
| 28 |
269800169 |
BOW ROLLER - Call your local BRP dealership |
| 29 |
296000429 |
GROMMET - Call your local BRP dealership |
| 31 |
269800173 |
KEEL PROTECTOR - Call your local BRP dealership |
| 32 |
269800175 |
BAKING PLATE - Call your local BRP dealership |
| 33 |
269800184 |
WASHER - Call your local BRP dealership |
| 34 |
269800299 |
CENTERLOCK NUT - Call your local BRP dealership |
| 35 |
269800300 |
FLAT WASHER - Call your local BRP dealership |
| 36 |
269800308 |
HEX. BOLT 1/2''-13 X 1-1/4'' - Call your local BRP dealership |
| 37 |
269800310 |
CENTERLOCK NUT 1/2-1 - Call your local BRP dealership |
| 38 |
269800138 |
U BOLT - Call your local BRP dealership This part replaces 269800400. |
| 39 |
269800464 |
U BOLT - Call your local BRP dealership |
| 40 |
269800480 |
U-BOLT 3/8''-16 X 3-1/8'' X 2-3/8'' - Call your local BRP dealership |
| 41 |
269800311 |
CARRIAGE BOLT 3/8''-16 X 7/8'' - Call your local BRP dealership |
| 45 |
291003552 |
LH WING BRACKET, GALVANIZE - Call your local BRP dealership |
| 45 |
291003554 |
LH WING BRACKET, BLACK - Call your local BRP dealership |
| 46 |
291003553 |
RH WING BRACKET, GALVANIZE - Call your local BRP dealership |
| 46 |
291003555 |
RH WING BRACKET, BLACK - Call your local BRP dealership |
| 47 |
291003780 |
Baking Plate |
