| Ref | Part Number | Description |
|---|
| 1 |
5030207 |
FITTING, GREASE |
| 2 |
5030821 |
BONDING LEAD, Exh. hsg. to bracket |
| 4 |
5032058 |
BUSH |
| 5 |
5032064 |
BUSH, STEERING |
| 6 |
5032352 |
PLATE, Steering arm, upper |
| 8 |
5030407 |
SCREW (5X8) |
| 9 |
5031851 |
WASHER |
| 10 |
5032353 |
SHIM, Steering arm, 0.3mm |
| 11 |
5030548 |
SEAL |
| 12 |
5030572 |
CIRCLIP |
| 13 |
5031907 |
KEY |
| 14 |
5031491 |
BUSH, TILT LOCK LEVER |
| 15 |
5031492 |
SPRING ASSY., Tilt lock |
| 16 |
5034248 |
LEVER, TILT LOCK STBD This part replaces 5032054. |
| 17 |
5034249 |
LEVER, TILT LOCK PORT This part replaces 5032055. |
| 18 |
5032069 |
BRACKET, Tilt Lock Spring |
| 20 |
5031249 |
PIN |
| 21 |
5032354 |
ADJUSTER, STEERING |
| 22 |
5031499 |
CACHE, DISPOSITIF DE RÉGLAGE DE DIRECTION |
| 23 |
5032355 |
BOLT (8X27) |
| 24 |
5031284 |
SPRING |
| 25 |
5030344 |
RONDELLE |
| 37 |
5031858 |
RONDELLE, ondulée |
| 43 |
5032049 |
STERN BRACKET, Stbd. |
| 44 |
5032050 |
STERN BRACKET, Port |
| 45 |
5032052 |
SCREW, Clamp |
| 46 |
5032053 |
HANDLE, Clamp |
| 49 |
5034365 |
SHAFT, CLAMP BRACKET This part replaces 5032051. |
| 50 |
5031489 |
CAP, CLAMP BRACKET |
| 51 |
5030839 |
CAP, TRANSOM BOLT |
| 52 |
5035786 |
ZINC SET, PROTECTION This part replaces 5030265. |
| 54 |
5037556 |
Kit This part replaces 5030385. |
| 55 |
5030418 |
NUT |
| 56 |
5030427 |
NUT, Tilt tube |
| 57 |
5030436 |
WASHER |
| 59 |
5031846 |
WASHER |
| 60 |
5030462 |
RONDELLE GROWER This part replaces 5031855. |
| 62 |
5032068 |
PIN, Tilit lock |
| 63 |
*5030054 |
NUT |
| 64 |
5030057 |
WASHER |
| 66 |
5032059 |
DECAL, Release lever |
| 5032200 |
*BIELLE, |
DIRECTION 5032200 |
| 5032200 |
*DRAG |
LINK 5032200 |
