| Ref | Part Number | Description |
|---|
| 1 |
0510397 |
SCREW |
| 3 |
0328731 |
VIS, câble de verrouillage This part replaces 0307055. |
| 4 |
0330151 |
CLAMP, Harness to oil tank boss This part replaces 0309846. |
| 5 |
0306049 |
SCREW |
| 6 |
0330151 |
CLAMP, Harness to oil tank boss This part replaces 0310440. |
| 8 |
0329240 |
SCREW This part replaces 0314451. |
| 9 |
0314476 |
SLEEE, Rectifier |
| 10 |
0314576 |
SCREW |
| 11 |
0314951 |
SCREEN, Mfld. to c'case |
| 12 |
0315003 |
SCREW, Teminal to terinmal block |
| 13 |
0315004 |
FIL DE LIAISON, bornier |
| 14 |
0317616 |
BRACKET, Electrical comp |
| 15 |
0317753 |
SCREW |
| 16 |
0317000 |
COLLIER, câble |
| 17 |
0376349 |
FIL, masse |
| 18 |
0581709 |
POWER PACK #4 ASSY. |
| 19 |
0330151 |
CLAMP, Harness to oil tank boss This part replaces 0309041. |
| 20 |
0386328 |
MOTOR CABLE ASSY |
| 29 |
0511091 |
IDENTIFICATION BAND, Spark plug #1 |
| 30 |
0511092 |
IDENTIFICATION BAND, Spark plug #2 |
| 31 |
0511093 |
IDENTIFICATION BAND, Spark plug #3 |
| 32 |
0511094 |
IDENTIFICATION BAND, Spark plug #4 |
| 34 |
0511050 |
TUBE, Heat shrink |
| 36 |
0580895 |
LEAD ASSY ., Ground |
| 37 |
0581610 |
COIL & YOKE ASSY. |
| 39 |
0551426 |
GORMMET |
| 42 |
0510767 |
RING TERMINAL |
| 43 |
0306778 |
ECREW,Exhaust cover,1-3/8"long |
| 44 |
0385531 |
COVER ASSEMBLEY |
| 44 |
0387991 |
COVER ASSEMBLY |
| 45 |
0307152 |
SCREW, Cliipper assemlby |
| 46 |
0510862 |
TERMINAL BLOCK |
| 47 |
0323547 |
SCREW This part replaces 0321720. |
| 48 |
0581553 |
COVER & TRANSFER ASSY. |
| 49 |
0320882 |
INSULATOR, Cover to case |
| 50 |
0320881 |
GASKET, Cover to pack |
| 51 |
0317000 |
COLLIER, câble This part replaces 0318190. |
| 52 |
0313666 |
RET., Distributor base 1 |
| 53 |
0581300 |
TIMBERBASE & SENSOR ASSY. |
| 56 |
0511329 |
SCREW |
| 57 |
0510409 |
CLAMP, H.T. lead |
| 58 |
0511331 |
SCREW |
| 59 |
0511194 |
SLEEVE,Timer base |
| 61 |
0581547 |
FLYWHEEL ASSY. |
| 62 |
0329267 |
NUT, Flywheel This part replaces 0314209. |
| 64 |
0581225 |
STATOR ASSY,6 amp |
| 68 |
0318865 |
SLEEVE, Rubber mount |
| 70 |
0316354 |
ENGINE COVER SUPPORT GROMMET |
| 71 |
0511071 |
CLIP |
| 71 |
0511072 |
CLIP |
| 71 |
0511073 |
CLIP, Sleeve coil #3 |
| 71 |
0511074 |
CLIP, Sleeve coil #4 |
