| Ref | Part Number | Description |
|---|
| 1 |
0385070 |
GEARCASE & BEARING ASSY |
| 4 |
0385057 |
OIL PUMP ASSEMBLY |
| 8 |
0314491 |
O RING |
| 10 |
0315709 |
PISTON HYDRULIC SHIFT |
| 17 |
0315164 |
BALL, Shift detent |
| 19 |
0316028 |
THRUST WAHER, Shifter dog fwd. |
| 23 |
0384607 |
PROPELLER SHAFT ASSY |
| 24 |
0316522 |
GEAR, Reverse |
| 33 |
0317178 |
O RING |
| 39 |
0385092 |
DRIVESHAFT ASSY, Std |
| 39 |
0385093 |
DRIVESHAFT ASSY, Long |
| 40 |
0313449 |
RETAINER, Clutch dog |
| 41 |
0313754 |
O RING |
| 44 |
0329894 |
SCREW This part replaces 0302510. |
| 47 |
0316961 |
TRIM TAB, Gearcase |
| 48 |
0313715 |
SCREW, Cap, hex hd, 7/16-14 x 1 |
| 49 |
0031426 |
WAVE WASHER, Solenoid |
| 50 |
0315710 |
COVER, Solenoid |
| 52 |
0383542 |
CABLE ASSEMBLY |
| 65 |
0315484 |
O RING |
| 67 |
0317667 |
SHIFTER, Clutch dog |
| 69 |
0314020 |
SPING, Propeller shaft |
| 71 |
0385259 |
GEAR ASSY., Fwd |
| 75 |
0317231 |
SHIM, . 002" |
| 77 |
0317165 |
THRUST WASHER, Fwd |
| 78 |
0310441 |
CLAMP, CPS lead This part replaces 0316385. |
| 80 |
0314765 |
GUIDE, Water tube |
| 82 |
0313815 |
IMPELLER HOUSING, Gearcase |
| 85 |
0307708 |
RONDELLE GROWER |
| 87 |
0306314 |
L'WASHER,Scr,long |
| 88 |
0313697 |
SCR,Grc to hsg.long |
| 90 |
0306503 |
SCREW, Short |
| 91 |
0317236 |
PLATE, Impeller housing |
| 92 |
0382547 |
IMPELLER ASSEMBLY |
| 97 |
0385098 |
COVER, Impeller housing |
| 101 |
0382761 |
PROPELLER ,14 x 11 |
| 101 |
0382765 |
PROPELLER 13 X 19 |
| 101 |
0382766 |
PROP. 12-3/4 X 21 (STD) |
| 101 |
0383160 |
PROPELLER 14 X 19 |
| 101 |
0384139 |
PROP., 13 - 3/8 x 17 - SST |
| 101 |
0384142 |
PROP., 13 x 19 - SST |
| 101 |
0389512 |
PRO, 12-3/4 x 21 sst cupped This part replaces 0384141. |
| 101 |
0765181 |
PROPELLER This part replaces 0382762. |
| 101 |
0765182 |
PROPELLER - W Models This part replaces 0382763. |
| 101 |
0765183 |
PROPELLER, WDEL Models This part replaces 0382764. |
| 102 |
0314188 |
CONVERGING RING |
| 0384459 |
0384459 |
SOLENOID CABLE & COVER ASSY |
| 0385094 |
0385094 |
GEARCASE ASSY., Complete std |
| 0385095 |
0385095 |
GEARCASE ASSY., Complete long |
