| Ref | Part Number | Description |
|---|
| 33 |
278000999 |
Wire Seal |
| 44 |
515175231 |
Female Terminal |
| 54 |
515175495 |
Female Housing, 3 Circuits |
| 62 |
278001014 |
Female Terminal |
| 70 |
409209700 |
Female Housing, 4 Circuits |
| 71 |
710000780 |
Connector |
| 73 |
278001013 |
Wire Seal |
| 77 |
409010300 |
Female Terminal |
| 79 |
710000038 |
Female Terminal |
| 99 |
278000992 |
Open Barrel |
| 112 |
278000632 |
Female Terminal |
| 138 |
293000052 |
Sealing Cap |
| 227 |
409004300 |
Male Terminal |
| 229 |
278000223 |
Female Terminal |
| 231 |
278000217 |
Female Housing, 2 Circuits |
| 238 |
278000273 |
Male Housing, 3 Circuits |
| 242 |
278000218 |
Wire Seal |
| 243 |
710000048 |
Wire Seal |
| 253 |
219704425 |
Tubing 6 Mm 3000Mm Long |
| 254 |
219704399 |
Was 409901700 Tubing (9 mm) |
| 255 |
219704400 |
Was 409901800 Tubing (13 mm) |
| 256 |
219704408 |
Tubing 16 Mm 1000Mm Long |
| 257 |
219704398 |
Was 409901600 Tubing 19mm |
| 260 |
219704423 |
Was 515175319 Tubing 22 mm |
| 279 |
409011300 |
Male Terminal |
| 280 |
409012100 |
Female Terminal |
| 286 |
409012300 |
Seal |
| 295 |
278001008 |
Insulated Sheath |
| 296 |
278000770 |
Insulated Sheath |
| 297 |
278001007 |
Insulated Sheath |
| 301 |
409012700 |
Diode |
| 318 |
278001477 |
FEMALE HOUSING, 4 CIRCUITS - Call your local BRP dealership |
| 319 |
515175568 |
Male Terminal |
| 334 |
710000081 |
Female Housing, 6 Circuits |
| 346 |
278001478 |
MALE WEDGE, 4 CIRCUITS - Call your local BRP dealership |
| 355 |
515175658 |
Female Housing, 2 Circuits |
| 365 |
515175672 |
CONNECTOR_MALE 4 CAVITIES - Call your local BRP dealership |
| 366 |
515175673 |
Male Housing, 6 Circuits |
| 371 |
515175678 |
Male Wedge, 6 Circuits |
| 387 |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| 401 |
278001505 |
WIRE SEAL - Call your local BRP dealership |
| 409 |
515175812 |
Plug |
| 410 |
515175801 |
Female Housing, 24 Circuits |
| 411 |
515175802 |
Retainer Block |
| 412 |
515175803 |
Wire Seal |
| 415 |
515175806 |
Female Terminal |
| 442 |
710000329 |
Male Housing, 4 Circuits |
| 443 |
710000335 |
Female Terminal |
| 464 |
710000274 |
Female Terminal |
| 478 |
710000888 |
Housing, 6 Circuits |
| 479 |
710000889 |
Lock |
| 484 |
415128501 |
Seal |
| 498 |
710000399 |
Female Housing |
| 499 |
710000402 |
Wire Seal |
| 506 |
710000421 |
Female Terminal |
| 524 |
Not |
Available As Spare Part - Shrink Tubing |
| 525 |
710000482 |
SHRINK TUBING - Call your local BRP dealership |
| 527 |
Not |
Available As Spare Part - Shrink Tubing |
| 579 |
710000504 |
Wire Seal |
| 641 |
710000667 |
Male Housing, 2 Circuits |
| 666 |
710000742 |
Little Fuse, 5 Amperes |
| 667 |
710000743 |
Little Fuse, 7.5 Amperes |
| 670 |
710000746 |
Little Fuse, 20 Amperes |
| 671 |
710000747 |
Little Fuse, 30 Amperes |
| 672 |
710000748 |
Diode |
| 675 |
415129856 |
Fuse Box Base Ass´y This part replaces 710000660. |
| 684 |
710000781 |
Fuse Puller |
| 690 |
710000890 |
Female Terminal |
| 700 |
710000835 |
Male Terminal Housing, 6 Circuits |
| 702 |
710000836 |
Female Terminal |
| 703 |
710000837 |
Female Terminal |
| 706 |
710000840 |
Cap |
| 709 |
710000848 |
Lock |
| 711 |
710000849 |
Male Housing, 6 Circuits |
| 732 |
710000877 |
Female Terminal |
| 734 |
710000879 |
Female Housing, 3 Circuits |
| 735 |
710000880 |
Housing, 3 Circuits |
| 736 |
710000881 |
Seal |
| 737 |
710000882 |
Cap |
| 738 |
710000897 |
Cover |
| 750 |
710000913 |
Terminal |
| 757 |
278001665 |
Female Terminal |
| 764 |
710000992 |
Clip |
| 773 |
710001026 |
Fuse Cover |
| 831 |
710001131 |
Female Terminal |
| 886 |
710001232 |
Housing |
| 888 |
710001230 |
Seal |
| 889 |
710001233 |
Seal |
| 890 |
710001229 |
Terminal |
| 891 |
710001228 |
Terminal |
| 893 |
710001226 |
Housing |
| 894 |
710001225 |
Cap |
| 898 |
710001221 |
LOCK - Call your local BRP dealership |
| 918 |
278002261 |
Female Terminal |
| 921 |
710001340 |
Female Terminal |
| 930 |
515176621 |
Wire Seal |
| 945 |
710001372 |
Fuse/Relay Decal |
| 957 |
710001435 |
HOUSING - Call your local BRP dealership |
| 958 |
710001436 |
TERMINAL - Call your local BRP dealership |
| 961 |
710001446 |
Male Housing Terminal, 6 Circuits |
| 967 |
278002172 |
Foam |
| 981 |
515176774 |
Relay, 30 AMP |
| 1028 |
710001635 |
Terminal |
| 1191 |
710002314 |
Housing |
| 1192 |
710002313 |
Housing |
| 1193 |
710002315 |
Terminal |
