06- Brakes - With Locking Rear Differential_22C1402a
Parts (16)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 705600628 | Banjo Bolt |
| 2 | 705601628 | Copper Washer This part replaces 705600310. |
| 4 | 293650256 | Clamp This part replaces 705600459. |
| 5 | 210251650 | Hex. Forming Screw M5 X 16 This part replaces 210251680. |
| 6 | 233251494 | Elastic Flange Nut M5 |
| 7 | 293150123 | Pop Rivet 3/16" |
| 8 | 390402200 | Pop Rivet 3/16" |
| 9 | 232561414 | Elastic Stop Nut M6 |
| 10 | 207661644 | Hex. Flange Screw M6 X 16 |
| 11 | 414115200 | Tie-Rap 180 mm |
| 12 | 517124300 | Washer |
| 14 | 705601231 | BRAKE SHIM KIT - Call your local BRP dealership |
| 15 | 705600711 | Brake Pad Kit |
| 16 | 705601057 | Rear Caliper Support |
| 17 | 250000060 | Flange Screw M10 X 16, Scotch Grip |
| 18 | 705601111 | Bracket |
