| Ref | Part Number | Description |
|---|
| 1 |
219904010 |
WARNING DECAL - Call your local BRP dealership This part replaces 219903238. |
| 3 |
219904018 |
SEA-DOO DECAL - Call your local BRP dealership |
| 7 |
262000044 |
COUPLER - Call your local BRP dealership |
| 8 |
262000045 |
SAFETY CABLE - Call your local BRP dealership |
| 16 |
262000267 |
BUNK ASS'Y, 72 (1500) - Call your local BRP dealership |
| 22 |
262000284 |
PROTECTOR - Call your local BRP dealership |
| 24 |
269800078 |
WINCH - Call your local BRP dealership |
| 24a |
296000328 |
WINCH STRAP - Call your local BRP dealership |
| 28 |
269800136 |
SCREW - Call your local BRP dealership |
| 33 |
269800169 |
BOW ROLLER - Call your local BRP dealership |
| 34 |
296000429 |
GROMMET - Call your local BRP dealership |
| 36 |
269800173 |
KEEL PROTECTOR - Call your local BRP dealership |
| 37 |
269800175 |
BAKING PLATE - Call your local BRP dealership |
| 40 |
269800299 |
CENTERLOCK NUT - Call your local BRP dealership |
| 41 |
269800300 |
FLAT WASHER - Call your local BRP dealership |
| 42 |
269800305 |
HEX. CAP SCREW 3/8 -16 X 1 - Call your local BRP dealership |
| 43 |
269800306 |
LARGE WASHER OD - Call your local BRP dealership |
| 45 |
269800310 |
CENTERLOCK NUT 1/2-1 - Call your local BRP dealership |
| 46 |
269800138 |
U BOLT - Call your local BRP dealership This part replaces 269800400. |
| 47 |
269800401 |
HEX. BOLT 1/2''-13 X 4'' - Call your local BRP dealership |
| 48 |
269800132 |
HEXAGONAL BOLT - Call your local BRP dealership This part replaces 269800402. |
| 50 |
269800480 |
U-BOLT 3/8''-16 X 3-1/8'' X 2-3/8'' - Call your local BRP dealership |
| 56 |
269800676 |
WINCH SUPPORT GALVANIZED - Call your local BRP dealership |
| 56 |
269801298 |
SUPPORT_WINCH PAINTED - Call your local BRP dealership This part replaces 269800679. |
| 57 |
269800677 |
ADJUSTABLE WINCH SUPPORT GALVANIZED - Call your local BRP dealership |
| 57 |
269800680 |
ADJUSTABLE WINCH SUPPORT PAINTED - Call your local BRP dealership |
| 64 |
269800317 |
HEX. BOLT 3/8''-16 X 4 1/2'' - Call your local BRP dealership |
