| Ref | Part Number | Description |
|---|
| 6 |
0314936 |
HEAT SHRINK |
| 7 |
0317753 |
SCREW |
| 8 |
0909618 |
BRACKET |
| 8 |
0910187 |
BRACKET |
| 9 |
0985063 |
SOLENOID This part replaces 0982187. |
| 10 |
0983321 |
FUSEHOLDER ASSY, Trim & tilt This part replaces 0982024. |
| 10 |
0983322 |
FUSE HOLDER & LEAD This part replaces 0982588. |
| 16 |
3852499 |
RETAINER, Fuse This part replaces 0910330. |
| 17 |
0909424 |
CLAMP |
| 18 |
0909450 |
BUS BAR |
| 19 |
0909617 |
BRACKET, Trim solenoid |
| 19 |
0909982 |
BRACKET, Trim solenoid |
| 20 |
0909988 |
BUSHING, Tilt & trim cable |
| 21 |
0981843 |
CABLE ASSY |
| 27 |
0982316 |
CABLE ASSY |
| 36 |
0510469 |
TAB |
| 37 |
0510471 |
CONNECTOR |
| 39 |
0981890 |
LEAAD ASSY |
| 41 |
0330151 |
CLAMP, Harness to oil tank boss This part replaces 0310440. |
| 41 |
3852434 |
CLAMP, Engine cable This part replaces 0908191. |
| 42 |
0910018 |
RETAINER, Fuse holder |
| 44 |
0306414 |
SCREW |
| 44 |
0306539 |
BOLT, Distributor |
| 45 |
0910091 |
CAP |
| 46 |
0306414 |
SCREW |
| 46 |
0317753 |
SCREW |
| 47 |
0120177 |
L'WASHER, Alternator to brkt |
| 49 |
0910162 |
SPACER |
| 50 |
0302471 |
W.ASHER, Plain |
| 52 |
0982377 |
CABLE ASSY |
| 60 |
0510469 |
TAB |
| 61 |
0510471 |
CONNECTOR |
| 63 |
0306407 |
LOCCKWASHER,Cover latch |
