07- Body - Decals
Parts (28)
| Ref | Part Number | Description |
|---|---|---|
| 3 | *STOPPER | BUSHING |
| 4 | 5040002 | Bague 13-2 |
| 5 | 5041557 | BOULON |
| 6 | 5040371 | GOUJON D’ASSEMBLAGE 6-12 |
| 7 | *STUD | Bolt |
| 8 | *DRIVE | SHAFT, 20 in. |
| 10 | 516010651 | BRP Logo 20 MM x 2 MM |
| 10 | CAM | ROD |
| 11 | SPRING | PIN 3-8 |
| 12 | WATER | PIPE ASSEMBLY, 20 in. |
| 15 | 704909041 | Emblem Logo BRP 68 MM UV |
| 30 | 704909040 | Emblem BRP Logo 48 MM UV |
| 125 | 516011041 | Central Hood Decal |
| 200 | 516009561 | Upper Side Panel Decal "600R E-TEC" |
| 300 | 516011047 | LH/RH Panel Decal |
| 500 | 516011045 | LH/RH Panel Decal |
| 700 | 516011055 | LH/RH Tunnel Decal |
| 800 | 516011053 | LH/RH Cross Member Decal |
| 1105 | 516011365 | Clutch Instruction Label |
| 1110 | 516011437 | Ramp Instruction Label |
| 1120 | 516011629 | Tool Instruction Label |
| 1535 | 516009954 | Protective Decal |
| 1540 | 516011681 | Decal Q-Link |
| 1550 | 516011683 | LH Decal Q-Link |
| 1560 | 516011682 | RH Decal Q-Link |
| 1800 | 516011049 | Decal PPS3 |
| 1805 | 516011051 | Decal Rave RE PPS3 |
| 1900 | 516008320 | Shock Adjustment Decal KYB |
