| Ref | Part Number | Description |
|---|
| 1 |
0582417 |
PLATE & SLEEVE ASSEMBLY |
| 5 |
0303714 |
SCREW |
| 6 |
0332063 |
PLATE, Support |
| 7 |
0303212 |
VIS, collier & capot |
| 8 |
0514481 |
SLEEVE |
| 9 |
0511460 |
VIS, dispositif de retenue |
| 10 |
0511458 |
COLLIER, fils |
| 11 |
0331626 |
COVER, Leads |
| 12 |
0585073 |
COIL & LAMINATION ASSY. |
| 15 |
0337522 |
VIS, ensemble bobine |
| 16 |
0582926 |
STATOR |
| 19 |
0319682 |
VIS, capteur vers plaque |
| 21 |
5001344 |
MODULE, Ignition This part replaces 0585074. |
| 30 |
0314576 |
SCREW This part replaces 0328720. |
| 32 |
0328731 |
VIS, câble de verrouillage |
| 33 |
0326111 |
NUT |
| 34 |
0584398 |
MOTOR CABLE ASSY,. |
| 47 |
0332070 |
SCREW, Retaining plate This part replaces 0326875. |
| 48 |
0302406 |
SLEEVE |
| 50 |
0582365 |
H.T. LEAD ASSEMBLY, Spark plugs to ignition coil |
| 55 |
0329895 |
BORNIER |
| 56 |
0328726 |
SCREW (Use existing coil screw) |
| 57 |
0322435 |
ROULEMENT, plaque d'allumage vers support |
| 58 |
0584261 |
FLYWHEEL Assy |
| 59 |
0326136 |
GROMMET |
| 60 |
0376349 |
FIL, masse |
| 61 |
0332790 |
RETAINER |
| 62 |
0329182 |
VIS, borne |
| 63 |
0583740 |
COIL Assy |
| 64 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 65 |
0585035 |
RECTIFIER & LEAD |
| 68 |
0338431 |
BRACKET |
| 71 |
0585072 |
SENSOR ASSEMBLY |
| 74 |
0335655 |
BOUCHON, étanchéité |
| 81 |
0583706 |
CABLE, Relay |
| 86 |
0584725 |
CABLE AY. |
| 87 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
