| Ref | Part Number | Description |
|---|
| 1 |
3853714 |
NUT, Solenoid This part replaces 0916168. |
| 2 |
3853717 |
ARMATURE This part replaces 0916173. |
| 3 |
3854200 |
FRAME & MAGNET This part replaces 0987889. |
| 4 |
0987891 |
BRUSH & HOLDER |
| 5 |
3854194 |
SOLENOID ASSY. This part replaces 0987883. |
| 6 |
3854195 |
SHAFT ASSY., Output This part replaces 0987884. |
| 7 |
3854198 |
GEAR ASSY., Planet This part replaces 0987887. |
| 8 |
3853720 |
RETAINER, Gear This part replaces 0916176. |
| 9 |
3853718 |
WASHER, Thrust This part replaces 0916174. |
| 10 |
3853736 |
E-RING, Output shaft This part replaces 0916247. |
| 10 |
517306115 |
Middle Hood |
| 11 |
250000528 |
Torx Screw M5 X 20 |
| 11 |
3854196 |
DRIVE ASSY. This part replaces 0987885. |
| 12 |
250000958 |
Panel Nut M5 X 0.8 |
| 12 |
3852713 |
RETAINER, Drive stop ring This part replaces 0913503. |
| 13 |
3852714 |
RING, Drive stop This part replaces 0913504. |
| 13 |
517306484 |
Black, RH Hood Front |
| 14 |
250000528 |
Torx Screw M5 X 20 |
| 14 |
3854197 |
SEAL ASSY. This part replaces 0987886. |
| 15 |
250000958 |
Panel Nut M5 X 0.8 |
| 15 |
3853721 |
BALL, Armature thrust This part replaces 0916177. |
| 16 |
3854199 |
HOUSING ASSY. This part replaces 0987888. |
| 16 |
517306485 |
LH Hood Front |
| 17 |
3853774 |
BEARING, Drive end This part replaces 0916451. |
| 18 |
3854203 |
PLATE & BUSHING This part replaces 0987892. |
| 19 |
3853773 |
BEARING, Plate This part replaces 0916450. |
| 20 |
250000528 |
Torx Screw M5 X 20 |
| 20 |
3853719 |
BOLT This part replaces 0916175. |
| 21 |
SCREW, |
Brush assy. |
| 22 |
SCREW, |
Solenoid |
| 23 |
3854223 |
PLANET GEAR ASSY. This part replaces 0987993. |
| 24 |
3853716 |
BEARING, Planet gear This part replaces 0916172. |
| 25 |
3853749 |
WEDGE, Gear assembly This part replaces 0916281. |
| 26 |
3854201 |
LEVER ASSY. This part replaces 0987890. |
| 27 |
0987812 |
LEAD, Starter |
| 30 |
0916197 |
COVER, Terminal |
| 30 |
250000958 |
Panel Nut M5 X 0.8 |
| 31 |
3853326 |
SCREW, Bracket to engine This part replaces 0914764. |
| 32 |
3852434 |
CLAMP, Engine cable This part replaces 0908191. |
| 100 |
517307222 |
RH Upper Side Panel |
| 105 |
517308487 |
RH Upper Side Panel Foam |
| 110 |
250000725 |
Screw M4 X 16 |
| 120 |
250000528 |
Torx Screw M5 X 20 |
| 130 |
250000958 |
Panel Nut M5 X 0.8 |
| 150 |
517306069 |
LH Upper Side Panel |
| 155 |
517308488 |
LH Upper Side Panel Foam |
| 160 |
250000725 |
Screw M4 X 16 |
| 170 |
250000528 |
Torx Screw M5 X 20 |
| 180 |
250000958 |
Panel Nut M5 X 0.8 |
| 195 |
517308121 |
Upper Side Panel Cap |
| 200 |
517307341 |
Rear Console |
| 210 |
250000958 |
Panel Nut M5 X 0.8 |
| 220 |
250000587 |
Torx Screw M5 X 26 |
| 230 |
250000587 |
Torx Screw M5 X 26 |
| 240 |
517306398 |
Foam Console |
| 245 |
517304518 |
Console Nut |
| 250 |
732610072 |
Push Nut |
| 360 |
517306808 |
Switch Hole Cap |
| 365 |
572051500 |
Cap |
| 500 |
517308531 |
RH Cover Plate |
| 510 |
517308532 |
LH Cover Plate |
| 600 |
517307676 |
Gauge Support |
| 800 |
517306187 |
Wind Deflector |
| 810 |
517303756 |
Grommet |
| 2400a |
415130081 |
Bulb |
| 3200b |
517305779 |
Latch |
| 3200c |
732610072 |
Push Nut |
| 3400b |
517305157 |
Seal Joint |
| 3800 |
517306824 |
Black, Head Lamp Bezel |
| 3810 |
250000528 |
Torx Screw M5 X 20 |
| 3820 |
250000958 |
Panel Nut M5 X 0.8 |
| 0987811 |
3854190 |
STARTER This part replaces 0987811. |
| 0988153 |
3854231 |
KIT, Hardware This part replaces 0988153. |
