| Ref | Part Number | Description |
|---|
| 2 |
420827445 |
DISTANCE RING - Call your local BRP dealership |
| 3 |
420832590 |
Ball Bearing 6206 |
| 4 |
420827050 |
RETAINING DISK - Call your local BRP dealership |
| 5 |
420427684 |
ADJUSTMENT WASHER - Call your local BRP dealership |
| 6 |
420931795 |
Oil Seal This part replaces 420931790. |
| 7 |
420827760 |
DISTANCE RING - Call your local BRP dealership |
| 8 |
420832575 |
Ball Bearing 6207 |
| 9 |
420931455 |
Oil Seal |
| 10 |
420927710 |
Retaining Disk |
| 11 |
420831952 |
Oil Seal |
| 12 |
420246015 |
Woodruff Key |
| 13 |
420945759 |
Lock Washer, 22 mm |
| 14 |
420842239 |
Hex. Nut, M22 X 1.5 This part replaces 420842234. |
| 15 |
420832439 |
Needle Bearing |
| 17 |
420815145 |
SEMI-TRAPEZ RING - Call your local BRP dealership |
| 18 |
420916136 |
PISTON PIN - Call your local BRP dealership |
| 19 |
420945735 |
Piston Circlip |
| 20 |
420832590 |
Ball Bearing 6206 |
| 21 |
420931940 |
Oil Seal |
| 22 |
420834350 |
Central Gear, 15 Teeth |
| 23 |
420818694 |
CRANKSHAFT, MAG - Call your local BRP dealership |
| 24 |
420818665 |
CRANKSHAFT, PTO SIDE - Call your local BRP dealership This part replaces 420818664. |
| 25 |
Not |
Available As Spare Part - Rod Repair Kit (MAG Side) |
| 26 |
293800060 |
Loctite 243, 10 ml |
| 27 |
219704461 |
LUBRICANT LOCTITE LB 8150 236ML - Call your local BRP dealership |
| 28 |
219703000 |
Sealant Loctite 648 This part replaces 413711400. |
| 29 |
779119 |
OIL 2T CARB PREM. MINERAL QT/0,946L This part replaces 413802900. |
| 30 |
420899271 |
Petamo Grease, GHY133N, 400 g |
