| Ref | Part Number | Description |
|---|
| BM |
278000992 |
Open Barrel |
| BM1 |
278000992 |
Open Barrel |
| BP |
278000992 |
Open Barrel |
| CM |
278002307 |
FEMALE TERMINAL - Call your local BRP dealership |
| CM |
293750002 |
Tie-Rap 142 mm |
| CM |
409209600 |
Female Housing, 3 Circuits |
| CM |
515176621 |
Wire Seal |
| COM |
278001665 |
Female Terminal |
| COM |
293000052 |
Sealing Cap |
| COM |
515175678 |
Male Wedge, 6 Circuits |
| COM |
710001540 |
CONNECTOR_MALE 6 CAVITIES - Call your local BRP dealership |
| CV |
515175801 |
Female Housing, 24 Circuits |
| CV |
515175802 |
Retainer Block |
| CV |
515175803 |
Wire Seal |
| CV |
515175806 |
Female Terminal |
| CV |
515175812 |
Plug |
| CV |
710000399 |
Female Housing |
| CV |
710001131 |
Female Terminal |
| DS |
515175231 |
Female Terminal |
| DS |
515175495 |
Female Housing, 3 Circuits |
| ECMB |
710001589 |
Female Terminal |
| ECMB |
710001590 |
Female Terminal |
| ECMB |
710001591 |
Cover, 48 positions |
| ECMB |
710001592 |
Plug |
| ECMB |
710001593 |
Plug |
| ECMB |
710001967 |
Molex Housing, 48 Circuits |
| ES |
293750002 |
Tie-Rap 142 mm |
| ES |
515175231 |
Female Terminal |
| ES |
515175658 |
Female Housing, 2 Circuits |
| FT |
515175231 |
Female Terminal |
| FT |
515175845 |
Female Terminal Housing, 4 Circuits |
| HG |
515175231 |
Female Terminal |
| HG |
515175282 |
Female Terminal |
| HG |
Not |
Available As Spare Part - Female Terminal Housing, 13 Circuits |
| HIC |
278000738 |
Male Lock, 4 Circuits |
| HIC |
278000739 |
Male Connector, 4 Circuits |
| HIC |
278001665 |
Female Terminal |
| HIC |
293000052 |
Sealing Cap |
| IR |
515175231 |
Female Terminal |
| IR |
515175658 |
Female Housing, 2 Circuits |
| NE |
515175232 |
Male Terminal |
| NE |
515175654 |
Male Terminal Housing, 2 Circuits |
| NV |
515176164 |
Male Terminal |
| NV |
515176621 |
Wire Seal |
| NV |
710000568 |
Male terminal housing |
| NV |
710000992 |
Clip |
| PA |
515176908 |
Female Housing |
| PA |
515176909 |
Terminal |
| PB |
515176908 |
Female Housing |
| PB |
515176909 |
Terminal |
| PE |
278001481 |
Female Terminal |
| PE |
409013700 |
Plug |
| PE |
710000643 |
Seal |
| PE |
710001132 |
Housing |
| PE |
710001133 |
Lock |
| PF1 |
278000216 |
Wire Seal |
| PF1 |
278000218 |
Wire Seal |
| PF1 |
278001065 |
Wire Seal |
| PF1 |
278002285 |
Fuse Box Ass'y |
| PF1 |
278002286 |
Fuse Box Cover |
| PF1 |
515176774 |
Relay, 30 AMP |
| PF1 |
516005569 |
FUSE DECAL - Call your local BRP dealership This part replaces 515176998. |
| PF1 |
710000742 |
Little Fuse, 5 Ampere |
| PF1 |
710000744 |
Little Fuse, 10 Ampere |
| PF1 |
710000745 |
Little Fuse, 15 Ampere |
| PF1 |
710000747 |
Little Fuse, 30 Amperes |
| PF1 |
710000890 |
Female Terminal |
| PF1 |
710000918 |
Female Terminal |
| PF2 |
278000216 |
Wire Seal |
| PF2 |
278000218 |
Wire Seal |
| PF2 |
278001065 |
Wire Seal |
| PF2 |
278002285 |
Fuse Box Ass'y |
| PF2 |
278002286 |
Fuse Box Cover |
| PF2 |
515176774 |
Relay, 30 AMP |
| PF2 |
515177015 |
FUSE RELAY DECAL - Call your local BRP dealership |
| PF2 |
710000745 |
Little Fuse, 15 Ampere |
| PF2 |
710000746 |
Little Fuse, 20 Ampere |
| PF2 |
710000890 |
Female Terminal |
| PF2 |
710000918 |
Female Terminal |
| RE |
710000877 |
Female Terminal |
| RE |
710000879 |
Female Housing, 3 Circuits |
| RE |
710000881 |
Seal |
| RE |
710000882 |
Cap |
| SA |
515175231 |
Female Terminal |
| SA |
515175495 |
Female Housing, 3 Circuits |
| SB |
515176164 |
Male Terminal |
| SB |
515176621 |
Wire Seal |
| SB |
710000568 |
Male terminal housing |
| SC |
515175919 |
Protector Cap |
| SC |
Not |
Available As Spare Part - Open Barrel |
| SD |
409010100 |
Female Terminal |
| SD |
409010400 |
Female Terminal Housing, 1 Circuit |
| VC |
515175658 |
Female Housing, 2 Circuits |
| 188 |
409902000 |
Tubing 12 mm |
| 1395 |
515175442 |
Tubing 6 mm |
| 1396 |
409901700 |
Tubing 9 mm |
| 1398 |
409901800 |
Tubing 13 mm |
| 1400 |
409901600 |
Tubing 19 mm |
