| Ref | Part Number | Description |
|---|
| 80 |
209641960 |
PHILLIPS TAPPING SCREW M4.2 X 19 - Call your local BRP dealership |
| 85 |
234041600 |
Flat Washer 4 mm, Stainless |
| 500 |
204471341 |
SWITCH SUPPORT - Call your local BRP dealership |
| 505 |
234041600 |
Flat Washer 4 mm, Stainless |
| 510 |
209642560 |
PHILLIPS SCREW M4.2 X 25 - Call your local BRP dealership |
| 520 |
204471339 |
BATTERY SWITCH - Call your local BRP dealership |
| 525 |
234051600 |
Flat Washer M5, Stainless |
| 530 |
205455060 |
SOCKET HEAD SCREW M5 X 50 - Call your local BRP dealership |
| 540 |
232051600 |
Hex. Nut M5 |
| 570 |
204471175 |
BATTERY SWITCH COVER - Call your local BRP dealership |
| 580 |
209641360 |
TAPPING PHILLIPS SCREW M4.2 X 13 - Call your local BRP dealership |
| 600 |
204471193 |
POSITIF SWITCH CABLE - Call your local BRP dealership |
| 650 |
204471190 |
RED CABLE, PORT SIDE - Call your local BRP dealership |
| 655 |
204471423 |
RED CABLE - Call your local BRP dealership |
| 690 |
204130176 |
SLIT CONDUIT 1 - Call your local BRP dealership |
| 1650 |
204470026 |
Courtesy Light Ass'y |
| 1651 |
204470081 |
BULB - Call your local BRP dealership |
| 1660 |
293150032 |
RIVET_POP 1/8 X ,487 - Call your local BRP dealership |
| 1670 |
204471169 |
LED Light Ass'y |
| 1671 |
204470652 |
Female Terminal |
| 1700 |
710001248 |
DC Outlet |
| 1750 |
204470908 |
LATERAL LIGHT KIT - Call your local BRP dealership |
| 1760 |
209941960 |
PHILLIPS SCREW M4.2 X 19 - Call your local BRP dealership |
| 1800 |
XXX |
Not Available As Spare Parts |
| 1810 |
XXX |
Not Available As Spare Parts |
| 1820 |
XXX |
Not Available As Spare Parts |
| 2000 |
204470801 |
HORN - Call your local BRP dealership |
| 2010 |
209943260 |
Phillips Tapping Screw M4.2 X 32 |
| 2200 |
204471344 |
SPEAKER, SILVER - Call your local BRP dealership |
| 2205 |
209641360 |
TAPPING PHILLIPS SCREW M4.2 X 13 - Call your local BRP dealership |
| 2220 |
278002705 |
REMOTE CONTROL DIGITAL - Call your local BRP dealership |
