| Ref | Part Number | Description |
|---|
| 2 |
0310913 |
GASKET |
| 3 |
0311567 |
GASKET |
| 4 |
0313810 |
HOUSING,Lower |
| 5 |
0380639 |
HOUSING ASSEMBLY,Upper |
| 6 |
0383307 |
TERMOSTAT ASSEMBLY This part replaces 0379754. |
| 7 |
0307057 |
SCREW, Lever to carburetor |
| 8 |
0382671 |
INTAKE MANIFOLD & STUD ASSEMBLY |
| 9 |
0552913 |
STUD, Gearcase to exh. hsg. |
| 10 |
0314056 |
HOSE, Inlet |
| 11 |
0379756 |
SWITCH, Water temperature |
| 12 |
0306453 |
LOCKWASHER, Fuel pump |
| 13 |
0306322 |
BOLT, Water pump |
| 14 |
0307899 |
CLAMP |
| 15 |
0310970 |
CAP |
| 17 |
0313793 |
HOSE |
| 18 |
0314055 |
HOSE, Outlet |
| 19 |
0313807 |
COVER,Manifold |
| 20 |
0313806 |
GASKET,Cover |
| 21 |
3852420 |
LOCKNUT, Throttle lever This part replaces 0900402. |
| 22 |
0314254 |
CLAMP |
| 23 |
0314060 |
SUPPORT,Manifold |
| 24 |
0132871 |
SCREW,Support to manifold |
| 25 |
0382747 |
LEVER & PIN |
| 26 |
0313812 |
SCREW |
| 27 |
0313809 |
ELBOW,Manifold |
| 28 |
0310685 |
ABCHOR BLCOK, Trunnion |
| 29 |
0310687 |
DETENT SPRING, Anchor block |
| 30 |
0310688 |
SAPCER, Anchor block |
| 31 |
0310894 |
CLAMP |
| 32 |
0314057 |
HOSE, Manifold to housing |
| 33 |
0308238 |
SCERW,Anchor block |
| 34 |
0310971 |
HOSE,Elbow to cover |
| 35 |
0312329 |
NUT |
| 36 |
0552914 |
WASHER, Guide pan |
| 37 |
0313808 |
MANIFOLD,Exhaust |
| 38 |
0307546 |
STUD |
| 39 |
0313794 |
GASKET, Housing |
| 40 |
0313850 |
GASKET,Manifold |
| 41 |
0310904 |
NIPPLE, Elbow |
| 42 |
0313795 |
HOSE, Elbow to housing |
| 43 |
0382733 |
CARBURETOR ASSEMBLY |
| 44 |
0312240 |
GASKET, Carb to manf 155 |
| 47 |
0310890 |
STUD, Flame arrestor |
| 48 |
0382878 |
FLAME ARRESTOR |
| 49 |
0314058 |
CONNECTOR |
| 50 |
0308419 |
WASHER |
| 51 |
0313457 |
NUT, Adapter stud |
| 52 |
0314038 |
STUD,Carburetor mounting |
| 53 |
0312329 |
NUT |
| 54 |
0314064 |
COVER, Heat exchanger |
| 56 |
0314065 |
TUBE,Heat exchanger |
| 57 |
0306344 |
BALL SLEEVE |
| 58 |
0306345 |
NUT, Tube |
| 59 |
0379779 |
VOLTAGE REGULATOR |
| 60 |
0303791 |
SCREW |
| 61 |
0307057 |
SCREW, Lever to carburetor |
| 62 |
0330151 |
CLAMP, Harness to oil tank boss This part replaces 0309322. |
| 63 |
0382748 |
FUEL LINE ASSEMBLY |
| 64 |
0551935 |
PIN, Manifold to anchor block |
| 65 |
0313845 |
MOUNT SUPPORT, Forward |
| 68 |
0382618 |
BRACKET, Rubber mount |
| 70 |
0312289 |
WASHER |
| 71 |
0378764 |
RUBBER MOUNT ASSY.,Lower |
| 71 |
0379931 |
RUBBER MOUNT, Rear |
| 72 |
0381519 |
ALTERNATOR ASSEMBLY |
| 73 |
0313798 |
BRACE, Alternator |
| 74 |
0302479 |
VIS, démarreur vers bloc cylindres-carter This part replaces 0306416. |
| 77 |
0313918 |
BELT |
| 78 |
0310503 |
CLAMP |
| 79 |
0510490 |
SCREW |
| 80 |
0311391 |
SCR,Altnr to brkt |
| 82 |
0309336 |
L'WASHER, Alternator to bracket |
| 84 |
0313796 |
BRACKET, Alternator |
| 85 |
0310896 |
SCREW |
