| Ref | Part Number | Description |
|---|
| 1 |
0323486 |
CAM, Throttle control |
| 2 |
0387793 |
RETAINER & LINK ASSY |
| 4 |
0322549 |
DISPOSITIF DE RETENUE, bouchon |
| 5 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 6 |
0322435 |
ROULEMENT, plaque d'allumage vers support |
| 7 |
0332063 |
PLATE, Support This part replaces 0323398. |
| 8 |
0324043 |
CAM, Starter interlock |
| 10 |
0332070 |
SCREW, Retaining plate This part replaces 0304442. |
| 11 |
0581927 |
POER PACK ASSY |
| 14 |
0511449 |
COMMECTOR, Coil to power pack |
| 16 |
0583916 |
FLYWHEEL ASSEMBLY This part replaces 0581675. |
| 17 |
0130541 |
NUT, Flywheel |
| 21 |
0583387 |
SENSOR ASSEMBLY This part replaces 0582069. |
| 25 |
0511460 |
VIS, dispositif de retenue |
| 26 |
0511458 |
COLLIER, fils |
| 27 |
0511459 |
CACHE, fils |
| 29 |
0581670 |
CHARGE COIL This part replaces 0582059. |
| 33 |
0511482 |
SLEEVE |
| 34 |
0581997 |
COIL ASSY |
| 37 |
0510767 |
RING TERMINAL |
| 38 |
0389856 |
SHORTIN SWITCH ASSY. |
| 43 |
0329110 |
VIS, boîtier d'échappement vers bloc cylindres-carter This part replaces 0324697. |
| 44 |
0306413 |
WASHER |
| 45 |
0322285 |
PLATE & SLEEVE ASSY. |
| 47 |
0329110 |
VIS, boîtier d'échappement vers bloc cylindres-carter This part replaces 0324697. |
| 51 |
0316362 |
CLIP, Link spring |
| 0582029 |
0582029 |
CHARGE COIL & PLATE ASSY |
