| Ref | Part Number | Description |
|---|
| 1 |
0387866 |
COVER,Air silencer |
| 2 |
0306409 |
VIS, collecteur vers carter-moteur |
| 3 |
0335633 |
GASKET This part replaces 0317504. |
| 4 |
0387309 |
CARB ASSY.,Upper |
| 5 |
0387310 |
CARB ASSY.,Lower |
| 6 |
0306474 |
SCREW |
| 7 |
0389810 |
LEAF PLATE This part replaces 0387431. |
| 9 |
0321497 |
GASKET, Air silencer |
| 10 |
0320679 |
GASKET, Base to cover |
| 11 |
0314807 |
SPRING |
| 12 |
0314496 |
SCREW, Air silencer |
| 13 |
0511514 |
CLAMP, Cable This part replaces 0317883. |
| 15 |
0311375 |
NUT This part replaces 0316659. |
| 16 |
0313329 |
LOCKWASHER, Carburetor link |
| 17 |
0303686 |
SCREW, Fastener |
| 18 |
0316073 |
LINK, Carburetor choke |
| 21 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 22 |
0316004 |
SCREW, clamp to c' case |
| 23 |
0316036 |
CLAMP CHOKE SOLENOID |
| 24 |
0391780 |
MANIFOLD ASSY This part replaces 0386687. |
| 27 |
0318974 |
FASTENER, Cable clamp |
| 28 |
0322088 |
BASE This part replaces 0320678. |
| 30 |
0325092 |
GASKET This part replaces 0314477. |
| 31 |
0316355 |
BUT, Carburetor mounting |
| 37 |
0330151 |
CLAMP, Harness to oil tank boss This part replaces 0309322. |
| 38 |
0316075 |
SPRING, Choke colenoid |
| 39 |
0316330 |
PLUNGER ,Choker solenoid |
| 40 |
0581748 |
SOLENOID ASSY,Choke,115,140 hp This part replaces 0387288. |
| 44 |
0314739 |
SPRING, Plunger to solenoid |
| 45 |
0307529 |
JOINT TORIQUE, galet vers contre-came |
| 46 |
0306409 |
VIS, collecteur vers carter-moteur |
| 47 |
0306418 |
VIS, ancrage |
| 50 |
0320976 |
Bushing,Choke lever |
| 51 |
0321071 |
LEVER, Throttle adjustment |
| 52 |
0320977 |
HANDLE,Choke |
| 53 |
0320975 |
LINK,Choke lever to housing |
| 54 |
0329888 |
LINK This part replaces 0321070. |
| 56 |
0320974 |
SPRING,Washer |
