Home / BRP / Can-Am SXS / 2020 / 005 - SSV - North America - Maverick Trail Series / 002 - Maverick Trail 1000 - North America, 2020 0007FLA00 0007FLC00 0007FLD00 0007FLE00 0007FLF00 0007FLG00 0007PLA00 0007PLB00 / MIDSECTION

MIDSECTION

MIDSECTION

Parts (89)

RefPart NumberDescription
1 0397731 SWIVEL BRACKET This part replaces 0389334.
5 0433458 ANODE, Port stern bracket This part replaces 0395780.
6 0326248 SCREW
7 0392517 STEERING ARM ASSEMBLY
8 0327696 CONTRE-CROU, arbre d'articulation
9 0321035 BRUSHING, Swivel bracket
10 0321673 COVER, Mount bracket lower This part replaces 0329288.
11 0329894 SCREW
12 0321507 MOUNT BRACKET
13 0320746 CROU, support de montage
14 0314024 SEAL HOUSING, Outer
15 0328598 EXHAUST HOUSING, Outer This part replaces 0330727.
16 0326900 SCREW, Exhaust housing This part replaces 0330714.
17 0309336 L'WASHER, Alternator to bracket
18 0387796 RUBBER MOUNT, Lower
19 0318612 SCREW, Bracket to cover
20 0307708 RONDELLE GROWER
21 0340777 COVER, Housing, rear This part replaces 0206006.
22 0329284 EXHAUST HOUSING
24 0319281 WASHER TUBE
24 0330203 WATER TUBE
25 0331016 GASKET
26 0330680 ADAPTER, Exhaust housing This part replaces 0330697.
27 0329894 SCREW
30 0328618 GASKET, Adapter to powerhead
31 0436394 RUBBER MOUNT ASSEMBLY, Upper This part replaces 0395873.
32 0306836 SCR,Altnr brkt
33 0321653 SCREW, Upper mount
34 0313580 WASHER
36 0331047 STERN BRACKET, Starboard
36 0395844 STEERING BRACKET, ASSY., Stbd.
38 0331019 DOWEL, Adapter to upper mount
40 0320792 PIN
42 0330373 COVER, Exhaust housing, front
43 0321054 SPRING CLIP
44 0363254 NUT, Stern bracket screw This part replaces 0321861.
45 0307238 RONDELLE
46 0320248 RONDELLE, écrou
47 0318273 Bolt hex retainer 1/2 in.
48 0319886 SCREW
49 0318572 Bolt thread protective cap 1/2 in.
50 0318573 SCREW, Bracket mount, 3 1/2 in. (12.7 x 89mm)
50 0363012 SCREW, Bracket mounting This part replaces 0313327.
51 0318272 Nut backing plate (square) 1/2 in.
52 0436541 ROD Assy, Thrust This part replaces 0387278.
53 0321053 SORUBG,Thrust rod
54 0396309 STERN BRACKET ASSEMBLY, Port
55 0390442 LOCATING LEVER, Rod
56 0321935 RETAINING PLATE
58 0329109 SHOULDER SCREW
59 0315511 NUT, Bracket to mount support
60 0306423 BOLT
61 0331021 MEGAPHONE This part replaces 0331020.
62 0323144 SPACER
64 0329110 VIS, boîtier d'échappement vers bloc cylindres-carter This part replaces 0319358.
65 0318612 SCREW, Bracket to cover
66 0329012 KNOB Tilt & reverse lock handle
67 0318238 SCREW
69 0204757 BOW WASHER
70 0302858 GOUPILLE, fendue - Tringlerie de verrouillage de marche arrière
71 0303887 WASHEER, Pin to swivel bracket
72 0319108 SCREW BELCRANK
73 0321246 BUSHING, Shock absorber, lower
74 0329519 SPACER Stern bracket
75 0321591 PIN, Link to locking
76 0321592 PIN, Link to swivel bracket
77 0332939 ROD, Reverse lock release This part replaces 0325709.
78 0321695 PIN, Cylinder, lower
79 0321748 LIN, Reverse lock, starboard
80 0325526 BELCRANK, Releasing rod
81 0321750 LOCKING LEVER, Reverse lock
82 0334345 RETAINER, Lock spring This part replaces 0323593.
83 0334345 RETAINER, Lock spring This part replaces 0323594.
84 0335814 DISPOSITIF DE RETENUE, ressort de verrouillage pour transport sur remorque This part replaces 0325525.
85 0321837 LINK, Reverse lock, port
89 0321920 SPRING, Reverse lock
90 0322085 SPRING, Trail lock return
92 0909676 SCREW
93 0387791 SHOCK ABSORBER
94 0390097 LEVER AND AHSFT
95 0319043 SEAL, Water tube upper
96 0584119 LEAD ASSEMBLY, Ground This part replaces 0388080.
97 0328696 SCREEN, Ground lead
98 0320866 RONDELLE DE BUTÉE, arbre d'articulation
100 0329241 RONDELLE
101 0335553 TILT TUBE This part replaces 0321052.
102 0323599 LOCKNUT This part replaces 0316828.
103 0351395 EXTENSION, Gearcase This part replaces 0329180.
104 0333738 STUD, Exhaust housing This part replaces 0329023.
