| Ref | Part Number | Description |
|---|
| 710 |
207582054 |
Hex Screw Washer Head M8 X 20 |
| 1100 |
705007794 |
LH Deflector |
| 1200 |
705007795 |
RH Deflector |
| 1300 |
705009027 |
LH Shell |
| 1310 |
250000586 |
Torx Truss M5 X 20 |
| 1320 |
414745900 |
Tuflock Phillips Plastic Screw |
| 1400 |
705009029 |
RH Shell |
| 1410 |
250000586 |
Torx Truss M5 X 20 |
| 1420 |
414745900 |
Tuflock Phillips Plastic Screw |
| 1500a |
705009144 |
LH Acoustic Fairing |
| 1500b |
705009344 |
Acoustic Foam |
| 1500c |
705009162 |
Acoustic Foam |
| 1500d |
708000759 |
Rubber Stopper |
| 1500e |
705007780 |
LH Engine Fairing |
| 1500f |
250000725 |
Screw M4 X 16 |
| 1510 |
205562060 |
Socket Head Screw M6 X 20, Scotch Grip |
| 1515 |
234061600 |
Stainless Flat Washer M6 |
| 1520 |
293730024 |
Dart, Fastex |
| 1600 |
705007781 |
RH Engine Fairing |
| 1610 |
205562060 |
Socket Head Screw M6 X 20, Scotch Grip |
| 1615 |
234061600 |
Stainless Flat Washer M6 |
| 1700a |
705013327 |
Deep Black, LH Front Fender |
| 1700b |
705012975 |
LH Inner Fender |
| 1700c |
250000805 |
Plastite Screw M4 X 10 |
| 1700d |
705013519 |
LH Front Fender Support Ass'y |
| 1700e |
250000805 |
Plastite Screw M4 X 10 |
| 1700f |
705013499 |
LH Light Protector |
| 1700g |
250000101 |
Plastite Screw Type K-40, M4 X 25 |
| 1700j |
705012404 |
Yellow, LH Reflector |
| 1700k |
705014736 |
Red, Rear Reflector |
| 1700l |
293720120 |
Plug |
| 1800a |
705013565 |
Deep Black, RH Front Fender |
| 1800b |
705012867 |
RH Inner Fender |
| 1800c |
250000805 |
Plastite Screw M4 X 10 |
| 1800d |
705012981 |
RH Front Fender Support Ass'y |
| 1800e |
250000805 |
Plastite Screw M4 X 10 |
| 1800f |
705013530 |
RH Light Protector |
| 1800g |
250000101 |
Plastite Screw Type K-40, M4 X 25 |
| 1800i |
705012405 |
Yellow, RH Reflector |
| 1800j |
705014736 |
Red, Rear Reflector |
