01- Exhaust System
Parts (64)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 707000100 | Rotax 4 strokes engine "610" |
| 2 | 715900637 | Spark Plug NGK DCPR8E This part replaces 707000246. |
| 3 | 234082410 | Flat Washer 8 mm |
| 4 | 707000094 | Anti-Vibration Mount |
| 5 | 293550010 | Synthetic Grease, 400 G |
| 6 | 707000019 | ENGINE SUPPORT BUSHING - Call your local BRP dealership |
| 7 | 707000174 | RUBBER MOUNT - Call your local BRP dealership |
| 8 | 707000159 | Engine Support, Black |
| 10 | 707000161 | Engine Bracket |
| 11 | 233201414 | Hex. Flange Elastic Nut M10 |
| 12 | 233281414 | Hex. Flange Elastic Nut M8 |
| 13 | 707000132 | LH FRONT ENGINE BRACKET, BLACK - Call your local BRP dealership |
| 14 | 707000101 | RH Front Engine Bracket, Black |
| 15 | 707000207 | RH Rear Engine Bracket |
| 16 | 707000210 | LH Rear Engine Bracket |
| 17 | 230604044 | Hex. Flange Screw M10 X 140 |
| 18 | 233201414 | Hex. Flange Elastic Nut M10 |
| 19 | 207682044 | Hex. Flange Screw M8 X 20 |
| 20 | 233281414 | Hex. Flange Elastic Nut M8 |
| 21 | 707200186 | CARBURATOR BSR42-8 - Call your local BRP dealership |
| 22 | 414420700 | Spring Clamp |
| 23 | 512059062 | Clamp |
| 24 | Not | Available As Spare Part - Engine Oil |
| 25 | 293550010 | Synthetic Grease, 400 G |
| 26 | 293300081 | O-RING - Call your local BRP dealership |
| 27 | 705500282 | SHIFTER HANDLE - Call your local BRP dealership |
| 28 | 707000103 | Bushing |
| 29 | 707000139 | Transmission Guide |
| 30 | 707000205 | PIVOT SLEEVE - Call your local BRP dealership |
| 31 | 705500283 | LEVER SPRING - Call your local BRP dealership |
| 32 | 207665044 | Hex. Flange Screw M6 X 50 |
| 33 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 |
| 34 | 707000187 | Guide Support |
| 35 | 707000169 | LOWER LEVER - Call your local BRP dealership |
| 36 | 207662044 | Hex. Flange Screw M6 X 20 |
| 37 | 207563034 | Hex. Flange Screw M6 X 30, Scotch Grip This part replaces 207663044. |
| 38 | 210261650 | Hex. Flange Screw M6 X 16 This part replaces 210261680. |
| 39 | 250200041 | Lock Washer Serrated M6 This part replaces 250200000. |
| 40 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 |
| 41 | 707600084 | TUNED PIPE - Call your local BRP dealership |
| 43 | 707600131 | Exhaust Support |
| 44 | 707600167 | Heat Shield Black |
| 45 | 707600168 | Heat Shield Black |
| 46 | 250000073 | HEX. FLANGED SCREW M6 X 12 - Call your local BRP dealership |
| 47 | 707600164 | Pipe Gasket |
| 48 | 707600165 | Exhaust Clamp |
| 49 | 707600130 | Tuned Pipe |
| 50 | 707600702 | Anti-Vibration Rubber This part replaces 707600012. |
| 51 | 707600076 | Heat Shield |
| 52 | 210261040 | Hex. Flange Screw M6 X 10 |
| 53 | 707600177 | SPRING - Call your local BRP dealership |
| 54 | 207661646 | Hex. Flange Screw M6 X 16 |
| 55 | 233061414 | Hex. Flange Nut M6 |
| 56 | 224060201 | Flat Washer |
| 57 | 293800060 | Loctite 243, 10 ml |
| 58 | 707000250 | THREADED INSERT - Call your local BRP dealership |
| 59 | 391301600 | Washer |
| 60 | 707000248 | Anti-vibration Mount |
| 61 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 |
| 62 | 707000243 | HOSE 3.5 MM, METER - Call your local BRP dealership |
| 63 | 207662044 | Hex. Flange Screw M6 X 20 |
| 64 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 |
| 707000251 | Ajout | Fileté 707000251 |
| 707000251 | Threaded | Insert 707000251 |
