| Ref | Part Number | Description |
|---|
| T16 |
0581670 |
CHARGE COIL This part replaces 0581635. |
| T6 |
0583387 |
SENSOR ASSEMBLY This part replaces 0581655. |
| 2 |
0583914 |
FLYWHEEL ASSEMBLY This part replaces 0582169. |
| 10 |
0303212 |
VIS, collier & capot |
| 12 |
0511460 |
VIS, dispositif de retenue |
| 13 |
0511458 |
COLLIER, fils |
| 14 |
0511459 |
CACHE, fils |
| 20 |
0511482 |
SLEEVE |
| 21 |
0324665 |
SCREW, Power pack to bracket |
| 23 |
0380226 |
REATINER ASSEMBLY |
| 24 |
0324664 |
SPACER, Throttle lever |
| 25 |
0322285 |
PLATE & SLEEVE ASSY. |
| 26 |
0322549 |
DISPOSITIF DE RETENUE, bouchon |
| 28 |
0306407 |
LOCCKWASHER,Cover latch |
| 30 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 31 |
0328088 |
CAM, Throttle control |
| 32 |
0580733 |
FIL, masse solénoïde |
| 33 |
0582106 |
COIL ASSY |
| 34 |
0510767 |
RING TERMINAL |
| 36 |
0306413 |
WASHER |
| 38 |
0321665 |
RETAINER |
| 39 |
0332063 |
PLATE, Support This part replaces 0323398. |
| 40 |
0322435 |
ROULEMENT, plaque d'allumage vers support |
| 41 |
0332070 |
SCREW, Retaining plate This part replaces 0304442. |
| 42 |
0581927 |
POER PACK ASSY |
| 44 |
0511449 |
COMMECTOR, Coil to power pack |
| 47 |
0324384 |
CONNECTOR, Cable |
| 48 |
0324663 |
SPACER, Cable connector |
| 49 |
0324386 |
CONNECTOR, Cable |
| 50 |
0324673 |
LEVER, Throttle control |
| 51 |
0582365 |
H.T. LEAD ASSEMBLY, Spark plugs to ignition coil |
| 54 |
0324671 |
LINK, Connector |
| 0582029 |
0582029 |
CHARGE COIL & PLATE ASSY |
