| Ref | Part Number | Description |
|---|
| 1 |
0986081 |
PARTIAL ENGINE |
| 2 |
3853007 |
DOWEL, Cylinder head This part replaces 0914133. |
| 3 |
3852650 |
PLUG, Core hole This part replaces 0912932. |
| 4 |
3853008 |
PLUG, Oil level hole This part replaces 0914134. |
| 5 |
3853108 |
PLUG, Oil gallery This part replaces 0914249. |
| 6 |
3853008 |
PLUG, Oil level hole This part replaces 0914134. |
| 7 |
3852766 |
PLUG, Rear, cam, standard This part replaces 0913704. |
| 7 |
3853009 |
PLUG, Rear, cam, 0.60 in. O.S. This part replaces 0914135. |
| 8 |
3853076 |
DOWEL, Adapter to block This part replaces 0914206. |
| 9 |
3853101 |
BOLT, Main cap This part replaces 0914231. |
| 10 |
3853102 |
STUD, Main cap This part replaces 0914232. |
| 11 |
3853026 |
NUT, Main cap This part replaces 0914153. |
| 12 |
3853010 |
PLUG, Oil gallery This part replaces 0914136. |
| 13 |
3852793 |
CRANKSHAFT This part replaces 0913733. |
| 14 |
3853268 |
RING SET, Standard This part replaces 0914555. |
| 14 |
3853269 |
RING SET, 0.020 in. O.S. This part replaces 0914556. |
| 14 |
3853270 |
RING SET, 0.030 in. O.S. This part replaces 0914557. |
| 14 |
3853271 |
RING SET, 0.040 in. O.S. This part replaces 0914558. |
| 15 |
3853886 |
PISTON ASSY., 0.003 in. O.S. This part replaces 0986034. |
| 15 |
3853898 |
PISTON, Standard, blue This part replaces 0986089. |
| 15 |
3853899 |
PISTON, Standard, red This part replaces 0986090. |
| 15 |
3853949 |
PISTON ASSY., 0.020 in. O.S. This part replaces 0986300. |
| 15 |
3853950 |
PISTON ASSY., 0.030 in. O.S. This part replaces 0986301. |
| 15 |
3853951 |
PISTON ASSY., 0.040 in. O.S. This part replaces 0986302. |
| 16 |
3852773 |
PIN, Piston, standard This part replaces 0913712. |
| 17 |
3852774 |
BEARING, Rod, standard This part replaces 0913713. |
| 17 |
3853079 |
BEARING, Rod, 0.001 in. U.S. This part replaces 0914209. |
| 17 |
3853080 |
BEARING, Rod, 0.002 in. U.S. This part replaces 0914210. |
| 17 |
3853081 |
BEARING, Rod, 0.010 in. U.S. This part replaces 0914211. |
| 17 |
3853082 |
BEARING, Rod, 0.020 in. U.S. This part replaces 0914212. |
| 17 |
3853083 |
BEARING, Rod, 0.030 in. U.S. This part replaces 0914213. |
| 18 |
3850393 |
CONNECTING ROD This part replaces 0986093. |
| 19 |
3852675 |
NUT, Connecting rod This part replaces 0913185. |
| 20 |
3852674 |
BOLT, Connecting rod This part replaces 0913184. |
| 21 |
3852779 |
CAMSHAFT This part replaces 0913719. |
| 22 |
0913741 |
BRG., Main, standard, upper |
| 22 |
3853084 |
BRG., Main, 0.001 in. U.S., upper This part replaces 0914214. |
| 22 |
3853085 |
BRG., Main, 0.002 in. U.S., upper This part replaces 0914215. |
| 22 |
3853086 |
BRG., Main, 0.010 in. U.S., upper This part replaces 0914216. |
| 22 |
3853087 |
BRG., Main, 0.020 in. U.S., upper This part replaces 0914217. |
| 22 |
3853088 |
BRG., Main, 0.030 in. U.S., upper This part replaces 0914218. |
| 23 |
0913742 |
BRG., Main, standard lower |
| 23 |
3853089 |
BRG., Main, 0.001 in. U.S., lower This part replaces 0914219. |
| 23 |
3853090 |
BRG., Main, 0.002 in. U.S., lower This part replaces 0914220. |
| 23 |
3853092 |
BRG., Main, 0.020 in. U.S., lower This part replaces 0914222. |
| 23 |
3853093 |
BRG., Main, 0.030 in. U.S., lower This part replaces 0914223. |
| 23 |
3858950 |
Main Brg Kit .010 This part replaces 0914221. |
| 24 |
0913743 |
BRG., Main, center, standard |
| 24 |
3853094 |
BRG., Main, center, 0.001 in. U.S. This part replaces 0914224. |
| 24 |
3853095 |
BRG., Main, center, 0.002 in. U.S. This part replaces 0914225. |
| 24 |
3853097 |
BRG., Main, center, 0.020 in. U.S. This part replaces 0914227. |
| 24 |
3853098 |
BRG., Main, center, 0.030 in. U.S. This part replaces 0914228. |
| 24 |
3858950 |
Main Brg Kit .010 This part replaces 0914226. |
| 25 |
3852780 |
BEARING, Front, standard This part replaces 0913720. |
| 25 |
3853018 |
BEARING, Front, 0.015 in. U.S. This part replaces 0914145. |
| 26 |
3852781 |
BEARING, Center, standard This part replaces 0913721. |
| 26 |
3853019 |
BEARING, Center, 0.015 in. U.S. This part replaces 0914146. |
| 27 |
3852782 |
BEARING, Rear, standard This part replaces 0913722. |
| 27 |
3853020 |
BEARING, Rear, 0.015 in. U.S. This part replaces 0914147. |
| 28 |
3852783 |
BEARING, Front intermediate, std. This part replaces 0913723. |
| 28 |
3853022 |
BEARING, Front intermediate, 0.015 in. U.S. This part replaces 0914149. |
| 29 |
3852784 |
BEARING, Rear intermediate, std. This part replaces 0913724. |
| 29 |
3853023 |
BEARING, Rear intermediate, 0.015 in. U.S. This part replaces 0914150. |
| 30 |
3852788 |
BOLT, Oil pump to block This part replaces 0913728. |
| 31 |
3852791 |
BOLT, Eccentric This part replaces 0913731. |
| 32 |
3852794 |
SPROCKET, Crankshaft This part replaces 0913734. |
| 33 |
3852796 |
KEY, Sprocket This part replaces 0913736. |
| 34 |
3852790 |
WASHER, Camshaft sprocket This part replaces 0913730. |
| 35 |
3852785 |
SPROCKET, Camshaft This part replaces 0913725. |
| 36 |
3852786 |
DOWEL PIN This part replaces 0913726. |
| 37 |
3852806 |
OIL SEAL, Rear This part replaces 0913746. |
| 38 |
3853904 |
DAMPER, Crankshaft This part replaces 0986095. |
| 39 |
3853021 |
BOLT, Damper This part replaces 0914148. |
| 40 |
3852673 |
ECCENTRIC, Fuel pump, outer This part replaces 0913176. |
| 41 |
3852789 |
ECCENTRIC, Fuel pump, inner This part replaces 0913729. |
| 42 |
3853903 |
CHAIN, Timing This part replaces 0986094. |
| 43 |
3852787 |
PLATE, Standard This part replaces 0913727. |
| 43 |
3853024 |
PLATE, 0.002 in. O.S. This part replaces 0914151. |
| 43 |
3853025 |
PLATE, 0.004 in. O.S. This part replaces 0914152. |
| 44 |
3853893 |
COVER, Front This part replaces 0986084. |
| 45 |
3852768 |
POINTER, Timing This part replaces 0913706. |
| 46 |
3853035 |
INSERT, Oil filter This part replaces 0914165. |
| 47 |
3853952 |
FLYWHEEL This part replaces 0986303. |
| 48 |
3852804 |
RING GEAR, Flywheel This part replaces 0913744. |
| 49 |
3853827 |
OIL SEAL, Front cover This part replaces 0984884. |
| 50 |
3853078 |
CLAMP, Distributor This part replaces 0914208. |
| 51 |
3853077 |
SCREW & WASHER, Clamp This part replaces 0914207. |
| 52 |
3853273 |
LOCKNUT, Coupler This part replaces 0914565. |
| 53 |
3853557 |
SCREW, Brace to alterntr bracket This part replaces 0915790. |
| 54 |
3853862 |
COUPLING, Flywheel This part replaces 0985727. |
| 55 |
3853274 |
STUD, Coupler This part replaces 0914566. |
| 56 |
3853003 |
COVER, Flywheel This part replaces 0914078. |
| 57 |
0502900 |
OIL FILTER This part replaces 0173231. |
| 58 |
3852421 |
SCREW, Baffle This part replaces 0907768. |
| 59 |
0379957 |
PETCHOCK ASSY, Water drain |
| 60 |
0980634 |
PULLEY, Crankshaft |
| 61 |
3853800 |
OIL PRESSURE SENDER This part replaces 0982650. |
| 62 |
3852767 |
GASKET, Front cover This part replaces 0913705. |
| 63 |
3853011 |
BOLT, Front cover, 2 in. This part replaces 0914137. |
| 63 |
3853012 |
BOLT, Cover to block, 1 3/4 in. This part replaces 0914138. |
| 63 |
3853013 |
BOLT, Front cover, 2 1/4 in. This part replaces 0914139. |
| 63 |
3853014 |
BOLT, Front cover, 2 1/2 in. This part replaces 0914140. |
| 64 |
3853075 |
WASHER, Damper This part replaces 0914205. |
| 65 |
3852711 |
FITTING, Sending unit This part replaces 0913490. |
