07- Body - Seat
Parts (22)
| Ref | Part Number | Description |
|---|
| 1 |
0284708 |
ENGINE COVER ASSY. |
| 1 |
0284709 |
ENGINE COVER ASSY. |
| 1 |
0284710 |
ENGINE COVER ASSY. |
| 1 |
0284809 |
ENGINE COVER ASSY. |
| 6 |
0212709 |
PLATE, Frame, front |
| 6 |
0212711 |
PLATE, Frame, front |
| 6 |
0212713 |
PLATE, Frame, front |
| 6 |
0212810 |
PLATE, Frame, front |
| 10a |
510007457 |
Seat Base |
| 10b |
510007458 |
Seat Foam |
| 10c |
510007696 |
Seat Cover |
| 13 |
0212710 |
PLATE, Frame, rear |
| 13 |
0212712 |
PLATE, Frame, rear |
| 13 |
0212714 |
PLATE, Frame, rear |
| 13 |
0212811 |
PLATE, Frame, rear |
| 15 |
510007203 |
Seat Base |
| 16 |
0212497 |
LENS, Ev. |
| 16 |
250000722 |
Torx Truss Screw M6 x 20 |
| 20 |
250000767 |
Torx Truss Screw M6 X 12 |
| 30 |
250200039 |
Flat Washer |
| 40 |
250200200 |
Flat Washer 6 MM |
| 50 |
250001000 |
Torx-Truss M/S M6 X 25 |
