| Ref | Part Number | Description |
|---|
| 10a |
715900402 |
J-Joint Cross Kit |
| 10b |
715900400 |
Fixed Yoke |
| 10c |
715900401 |
Yoke |
| 15a |
715900402 |
J-Joint Cross Kit |
| 15b |
715900401 |
Yoke |
| 16 |
705403522 |
Ball Bearing Ass'y This part replaces 705401938. |
| 17 |
293370098 |
Snap Ring |
| 18 |
207502046 |
Hex. Flange Screw M10 X 20 |
| 40a |
715900440 |
JOINT_CV EXT - Call your local BRP dealership |
| 40b |
715900441 |
RH Plunging Joint |
| 40c |
705401349 |
Circlip Joint |
| 40d |
705401345 |
Boot Kit, Wheel Side |
| 40e |
715900282 |
Oetiker Clamp |
| 40f |
715900283 |
Oetiker Clamp, Small |
| 40g |
705401355 |
Boot Kit, Différential Side |
| 40h |
715900261 |
Oetiker Clamp, Small |
| 40j |
715900262 |
Oetiker Clamp, Large |
| 50a |
715900440 |
JOINT_CV EXT - Call your local BRP dealership |
| 50b |
715900442 |
Joint Plongeant GA |
| 50c |
705401349 |
Circlip Joint |
| 50d |
705401345 |
Boot Kit, Wheel Side |
| 50e |
715900282 |
Oetiker Clamp |
| 50f |
715900283 |
Oetiker Clamp, Small |
| 50g |
705401355 |
Boot Kit, Différential Side |
| 50h |
715900261 |
Oetiker Clamp, Small |
| 50j |
715900262 |
Oetiker Clamp, Large |
| 60 |
293350150 |
Ball Bearing |
| 80 |
293370019 |
Circlip |
| 100 |
207502546 |
Hex. Flange Screw M10 X 25 |
| 110 |
234201474 |
Conical Spring Washer 10 mm |
| 130 |
705502338 |
Wheel Hub |
| 140 |
250300055 |
Wheel Stud M10 X 1.25 |
| 150 |
250200170 |
Conical Spring Washer M20 |
| 160 |
250100193 |
Castle Nut M20 |
| 170 |
250400084 |
Cotter Pin |
| 180 |
219704389 |
Polyurethane Hose 4000MM Long |
| 320 |
250001050 |
Hex. Flange Screw M8 X 42 |
