| Ref | Part Number | Description |
|---|
| B |
710001588 |
Female Terminal Housing, 48 Circuits |
| B |
710001589 |
Female Terminal |
| B |
710001591 |
Cover, 48 positions |
| B |
710001592 |
Plug |
| B |
710001593 |
Plug |
| B |
710001727 |
Female Terminal |
| B |
710001728 |
Terminal |
| BAT1 |
710002577 |
Heat Shrink |
| BAT1 |
710002712 |
Tie-Rap |
| BAT2 |
710002577 |
Heat Shrink |
| BAT2 |
710006005 |
Open Barell |
| BN1 |
710000475 |
TERMINAL_FEMALE - Call your local BRP dealership |
| BN1 |
710002577 |
Heat Shrink |
| BN3 |
710000913 |
Terminal |
| BN3 |
710002577 |
Heat Shrink |
| BP1 |
515177246 |
Shrink Tubing, 6 mm |
| BP1 |
710006801 |
Open Barell |
| BP2 |
278000992 |
Open Barrel |
| BP2 |
710000693 |
Terminal |
| BP2 |
710002576 |
Heat Shrink |
| BP2 |
710007033 |
Cap Battery Cable |
| CC |
710000274 |
Female Terminal |
| CC |
710000848 |
Lock |
| CC |
710000849 |
Male Housing, 6 Circuits |
| CC16 |
710006686 |
Female Terminal Housing 16 Circuits |
| CC16 |
710006688 |
Terminal |
| CC20 |
710006687 |
Female Terminal Housing 20 Circuits |
| CC20 |
710006688 |
Terminal |
| CL |
278002858 |
Female Housing 20 Circuits |
| CL |
278002860 |
Sealing Cap |
| CL |
515178018 |
Female Terminal |
| CL |
515178349 |
Female Terminal 22 AWG |
| CL_KEYPAD |
710001161 |
Housing |
| CL_KEYPAD |
710001162 |
Lock |
| CL_KEYPAD |
710001163 |
Wire Seal |
| CL_KEYPAD |
710001164 |
Female Terminal |
| C_AC_W0 |
278000230 |
Male Terminal |
| C_AC_W0 |
278001008 |
Insulated Sheath |
| C_AC_W1 |
278000230 |
Male Terminal |
| C_AC_W1 |
278001008 |
Insulated Sheath |
| C_AC_W11 |
278000230 |
Male Terminal |
| C_AC_W11 |
278001008 |
Insulated Sheath |
| C_AC_W2 |
278000230 |
Male Terminal |
| C_AC_W2 |
278001008 |
Insulated Sheath |
| C_AC_W3 |
278000230 |
Male Terminal |
| C_AC_W3 |
278001008 |
Insulated Sheath |
| C_AC_W4 |
278000230 |
Male Terminal |
| C_AC_W4 |
278001008 |
Insulated Sheath |
| C_AC_W5 |
278000230 |
Male Terminal |
| C_AC_W5 |
278001008 |
Insulated Sheath |
| C_AC_W6 |
278000230 |
Male Terminal |
| C_AC_W6 |
278001008 |
Insulated Sheath |
| C_AC_W7 |
278000230 |
Male Terminal |
| C_AC_W7 |
278001008 |
Insulated Sheath |
| C_AC_W8 |
278000230 |
Male Terminal |
| C_AC_W8 |
278001008 |
Insulated Sheath |
| C_AC_W9 |
278000230 |
Male Terminal |
| C_AC_W9 |
278001008 |
Insulated Sheath |
| D1 |
409012700 |
Diode |
| D2 |
409012700 |
Diode |
| DC1 |
710005373 |
Housing |
| DC1 |
710005518 |
Terminal |
| DC2_1 |
409010300 |
Female Terminal |
| DC2_2 |
409010300 |
Female Terminal |
| DC3 |
515175231 |
Female Terminal |
| DC3 |
515175658 |
Female Housing, 2 Circuits |
| DC3_CAP |
710000667 |
Male Housing, 2 Circuits |
| DESS |
710001161 |
Housing |
| DESS |
710001162 |
Lock |
| DESS |
710001163 |
Wire Seal |
| DESS |
710001164 |
Female Terminal |
| DESS |
710001225 |
Cap |
| DIFF |
710002000 |
Housing |
| DIFF |
710003047 |
Terminal |
| DIFF |
710005491 |
Female Terminal |
| DLC |
710002705 |
Lock |
| DLC |
710002706 |
Female Housing 6 Circuits |
| DLC |
710005437 |
Plug |
| DLC |
710005438 |
Female Terminal |
| DLC |
710005439 |
Female Terminal |
| DPS |
278002186 |
Wire Seal |
| DPS |
278002187 |
Female Terminal |
| DPS |
710001222 |
Lock |
| DPS |
710001873 |
Terminal |
| DPS |
710002075 |
Plug |
| DPS |
710003153 |
Seal |
| DPS |
710004989 |
Female Housing |
| DPS |
710005098 |
Lock |
| FRA |
515175658 |
Female Housing, 2 Circuits |
| FRA |
710003896 |
Female Terminal |
| FT |
278000217 |
Female Housing, 2 Circuits |
| FT |
278000218 |
Wire Seal |
| FT |
409004300 |
Male Terminal |
| FT |
710000992 |
Clip |
| F_AC_W0 |
278001007 |
Insulated Sheath |
| F_AC_W0 |
278001009 |
Female Terminal |
| F_AC_W1 |
278001007 |
Insulated Sheath |
| F_AC_W1 |
278001009 |
Female Terminal |
| F_AC_W2 |
278001007 |
Insulated Sheath |
| F_AC_W2 |
278001009 |
Female Terminal |
| F_AC_W3 |
278001007 |
Insulated Sheath |
| F_AC_W3 |
278001009 |
Female Terminal |
| HIBM |
710002001 |
Housing Connector |
| HIBM |
710003047 |
Terminal |
| HIBM |
710003048 |
Terminal |
| HIBM |
710005491 |
Female Terminal |
| HIBM_JMP_F |
515175231 |
Female Terminal |
| HIBM_JMP_F |
515175658 |
Female Housing, 2 Circuits |
| HIBM_JMP_M |
515175232 |
Male Terminal |
| HIBM_JMP_M |
515175654 |
Male Terminal Housing, 2 Circuits |
| HIC |
710001222 |
Lock |
| HIC |
710001225 |
Cap |
| HIC |
710001228 |
Terminal |
| HIC |
710001229 |
Terminal |
| HIC |
710001233 |
Seal |
| HIC |
710001332 |
Seal Wire |
| HIC |
710001930 |
Female Housing, 12 Circuits |
| HIC |
710006333 |
Lock |
| HIC9_F |
710001222 |
Lock |
| HIC9_F |
710001228 |
Terminal |
| HIC9_F |
710001229 |
Terminal |
| HIC9_F |
710001233 |
Seal |
| HIC9_F |
710001332 |
Seal Wire |
| HIC9_F |
710001930 |
Female Housing, 12 Circuits |
| HIC9_F |
710006333 |
Lock |
| HL_LH |
278002578 |
Female Terminal |
| HL_LH |
710001427 |
Wire Seal |
| HL_LH |
710002578 |
Housing |
| HL_LH |
710002584 |
Lock |
| HL_LL |
278002578 |
Female Terminal |
| HL_LL |
710001427 |
Wire Seal |
| HL_LL |
710002578 |
Housing |
| HL_LL |
710002584 |
Lock |
| HL_RH |
278002578 |
Female Terminal |
| HL_RH |
710001427 |
Wire Seal |
| HL_RH |
710002578 |
Housing |
| HL_RH |
710002584 |
Lock |
| HL_RL |
278002578 |
Female Terminal |
| HL_RL |
710001427 |
Wire Seal |
| HL_RL |
710002578 |
Housing |
| HL_RL |
710002584 |
Lock |
| HVAC_F |
409012100 |
Female Terminal |
| HVAC_F |
710000153 |
Female Terminal Housing, 3 Circ. |
| HVAC_F |
710000402 |
Wire Seal |
| HVAC_FAN_F |
278001473 |
Female Terminal Housing, 4 Circuits |
| HVAC_FAN_F |
278001474 |
Female Lock, 4 Circuits |
| HVAC_FAN_F |
515175567 |
Female Terminal |
| HVAC_SENSOR |
710001225 |
Cap |
| HVAC_SENSOR |
710001226 |
Housing |
| HVAC_SENSOR |
710001229 |
Terminal |
| HVAC_SENSOR |
710001233 |
Seal |
| OUTSIDE_RTD |
710007152 |
Temperature Sensor |
| PF1 |
278000216 |
Wire Seal |
| PF1 |
278000218 |
Wire Seal |
| PF1 |
278001065 |
Wire Seal |
| PF1 |
278002578 |
Female Terminal |
| PF1 |
278003448 |
Fuse Base Ass'y |
| PF1 |
278003553 |
Fuse Cover |
| PF1 |
293300198 |
Seal |
| PF1 |
515177177 |
Female Terminal |
| PF1 |
710000048 |
Wire Seal |
| PF1 |
710000918 |
Female Terminal |
| PF1_STD_LABEL |
710006953 |
Fuse Box Decal |
| PF2 |
278000216 |
Wire Seal |
| PF2 |
278000218 |
Wire Seal |
| PF2 |
278001065 |
Wire Seal |
| PF2 |
278002578 |
Female Terminal |
| PF2 |
278003448 |
Fuse Base Ass'y |
| PF2 |
278003553 |
Fuse Cover |
| PF2 |
293300198 |
Seal |
| PF2 |
710000890 |
Female Terminal |
| PF2 |
710000918 |
Female Terminal |
| PF2_HVAC_LABEL |
710007128 |
Relay Decal |
| PF2_SP1 |
710000744 |
Little Fuse, 10 Amperes |
| PF2_SP2 |
710000744 |
Little Fuse, 10 Amperes |
| PF2_SP3 |
710000744 |
Little Fuse, 10 Amperes |
| PF3 |
278001325 |
Fuse Holder |
| PF3 |
710000113 |
Female Terminal |
| PF4 |
278001325 |
Fuse Holder |
| PF4 |
710000113 |
Female Terminal |
| PF5 |
278000216 |
Wire Seal |
| PF5 |
278000218 |
Wire Seal |
| PF5 |
278002285 |
Fuse Box Ass'y |
| PF5 |
278002286 |
Fuse Box Cover |
| PF5 |
278002578 |
Female Terminal |
| PF5 |
710000890 |
Female Terminal |
| PF5 |
710001427 |
Wire Seal |
| PF5 |
710006791 |
Fuse Box Decal |
| PPS |
515177151 |
Housing |
| PPS |
710001229 |
Terminal |
| PPS |
710001233 |
Seal |
| PPS |
710005296 |
Lock 6 Positions |
| P_ACC |
515177247 |
Female Housing, 3 Circuits |
| P_ACC |
710006749 |
Folded Terminal Eyelet This part replaces 710006742. |
| RS_485 |
515175845 |
Female Terminal Housing, 4 Circuits |
| RS_485 |
710003896 |
Female Terminal |
| R_AC_W10 |
278001007 |
Insulated Sheath |
| R_AC_W10 |
278001009 |
Female Terminal |
| R_AC_W11 |
278001007 |
Insulated Sheath |
| R_AC_W11 |
278001009 |
Female Terminal |
| R_AC_W4 |
278001007 |
Insulated Sheath |
| R_AC_W4 |
278001009 |
Female Terminal |
| R_AC_W5 |
278001007 |
Insulated Sheath |
| R_AC_W5 |
278001009 |
Female Terminal |
| R_AC_W6 |
278001007 |
Insulated Sheath |
| R_AC_W6 |
278001009 |
Female Terminal |
| R_AC_W7 |
278001007 |
Insulated Sheath |
| R_AC_W7 |
278001009 |
Female Terminal |
| R_AC_W8 |
278001007 |
Insulated Sheath |
| R_AC_W8 |
278001009 |
Female Terminal |
| R_AC_W9 |
278001007 |
Insulated Sheath |
| R_AC_W9 |
278001009 |
Female Terminal |
| SB |
278001482 |
Seal |
| SB |
710001134 |
Female Terminal |
| SB |
710002043 |
Lock |
| SB |
710002177 |
Housing |
| SIG_L |
515177192 |
Female Housing, 2 Circuits |
| SIG_L |
710001152 |
Lock |
| SIG_L |
710001163 |
Wire Seal |
| SIG_L |
710001164 |
Female Terminal |
| SIG_R |
515177192 |
Female Housing, 2 Circuits |
| SIG_R |
710001152 |
Lock |
| SIG_R |
710001163 |
Wire Seal |
| SIG_R |
710001164 |
Female Terminal |
| SS |
515177192 |
Female Housing, 2 Circuits |
| SS |
710001152 |
Lock |
| SS |
710001153 |
Seal Wire |
| 2X4 |
710002000 |
Housing |
| 2X4 |
710003047 |
Terminal |
| 2X4 |
710005491 |
Female Terminal |
