05- Suspension - Rear Shocks
Parts (22)
| Ref | Part Number | Description |
|---|---|---|
| 2 | 0126822 | COVER, Oil tank |
| 18 | 0329661 | SUPPORT/BOUCHON |
| 19 | 0322654 | PINCE RAPIDE, flexible d'huile |
| 24 | 0175748 | LEAD ASSY. |
| 5000 | 503195569 | Center Shock |
| 5010 | 503193294 | Spring 220 MM-40 N/MM |
| 5040 | 230078 | Adjusting Cam |
| 5050 | 503195685 | Spacer |
| 5060 | 503196528 | Stopper Spring |
| 5080 | 31094 | Cushion |
| 5090 | 5446652 | Bushing |
| 5150 | 207004544 | Hex. Screw M10 X 45 |
| 5160 | 232500416 | Elastic Stop Nut M10 |
| 5500 | 503195571 | Rear Shock |
| 5510 | 503195567 | Black, Spring 280 MM-45 N/MM |
| 5540 | 230078 | Adjusting Cam |
| 5550 | 503195685 | Spacer |
| 5560 | 503196528 | Stopper Spring |
| 5570 | 5446652 | Bushing |
| 5580 | 503195134 | Glide Bearing |
| 5590 | 40134 | Screw Socket HD.DIN 912 |
| 0175953 | 5008617 | OIL TANK. Assy This part replaces 0175953. |
