| Ref | Part Number | Description |
|---|
| AT |
278000992 |
Open Barrel |
| AT |
710001163 |
Wire Seal |
| AT |
710001164 |
Female Terminal |
| BM |
515177246 |
Shrink Tubing, 6 mm |
| CD1 |
515175504 |
Ring Terminal |
| CD1 |
515177246 |
Shrink Tubing, 6 mm |
| CD2 |
409209600 |
Female Housing, 3 Circuits |
| CD2 |
515175504 |
Ring Terminal |
| CM |
293750002 |
Tie Wrap 142 mm |
| CM |
515175673 |
Male Housing, 6 Circuits |
| CM |
515176621 |
Wire Seal |
| CM |
710001340 |
Female Terminal |
| COM |
278000632 |
Female Terminal |
| COM |
293000052 |
Sealing Cap |
| COM |
515175665 |
Male Terminal Housing, 2 Circuits |
| COM |
515175678 |
Male Wedge, 6 Circuits |
| CP |
278000631 |
Male Terminal |
| CP |
409207500 |
Male Lock, 2 Circuits |
| CP |
515175801 |
Female Housing, 24 Circuits |
| CV |
409012700 |
Diode |
| CV |
515175802 |
Retainer Block |
| CV |
515175803 |
Wire Seal |
| CV |
515175806 |
Female Terminal |
| CV |
515175812 |
Plug |
| CV |
710000399 |
Female Housing |
| CV |
710001131 |
Female Terminal |
| D1 |
515175495 |
Female Housing, 3 Circuits |
| D1 |
515177247 |
Female Housing, 3 Circuits |
| DS |
278001005 |
Male Housing, 2 Circuits |
| DS |
515175231 |
Female Terminal |
| DT |
278000998 |
Female Terminal |
| DT |
415128501 |
Seal |
| DT |
515175665 |
Male Terminal Housing, 2 Circuits |
| EI |
278000631 |
Male Terminal |
| EI |
409207500 |
Male Lock, 2 Circuits |
| EI |
415128500 |
Female Terminal Housing, 2 Circuits |
| ER |
278000998 |
Female Terminal |
| ER |
415128501 |
Seal |
| ER |
710000568 |
Housing |
| ERF |
515176164 |
Male Terminal |
| ERF |
515176621 |
Wire Seal |
| ERF |
710000992 |
Clip |
| FA |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| FA |
409004000 |
Fuse Holder |
| FA |
409004200 |
Female Terminal |
| FA |
710000992 |
Clip |
| FB |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| FB |
278000344 |
Fuse, 5 Amperes |
| FB |
409004000 |
Fuse Holder |
| FB |
409004200 |
Female Terminal |
| FB |
409011600 |
Female Terminal |
| FB |
710000992 |
Clip |
| FC |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| FC |
278000343 |
Fuse, 15 Amperes |
| FC |
409004000 |
Fuse Holder |
| FC |
409011600 |
Female Terminal |
| FC |
515175349 |
FEMALE TERMINAL HOUSING, 13 CIRCUITS - Call your local BRP dealership |
| HG |
409209600 |
Female Housing, 3 Circuits |
| HG |
515175231 |
Female Terminal |
| HG |
515175282 |
Female Terminal |
| IGM |
278001013 |
Wire Seal |
| IGM |
278001014 |
Female Terminal |
| IGM |
409209600 |
Female Housing, 3 Circuits |
| IGP |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| IGP |
278001013 |
Wire Seal |
| IGP |
278001014 |
Female Terminal |
| INM |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| INM |
278001013 |
Wire Seal |
| INM |
278001014 |
Female Terminal |
| INM |
409209500 |
Female Housing, 2 Circuits |
| INM |
710002712 |
Tie-Rap |
| INP |
278001013 |
Wire Seal |
| INP |
278001014 |
Female Terminal |
| INP |
409209500 |
Female Housing, 2 Circuits |
| INP |
515176342 |
Female Terminal Housing, 34 Circuits |
| INP |
710002712 |
Tie-Rap |
| J1A |
515175812 |
Plug |
| J1A |
515176341 |
Female Terminal Housing, 26 Circuits |
| J1A |
515176348 |
Female Terminal |
| J1A |
515176541 |
Female Terminal |
| J1B |
515175812 |
Plug |
| J1B |
515176340 |
Female Terminal Housing, 16 Circuits |
| J1B |
515176348 |
Female Terminal |
| J1B |
515176541 |
Female Terminal |
| J2 |
278000998 |
Female Terminal |
| J2 |
415128501 |
Seal |
| J2 |
515175668 |
Male Terminal Housing, 6 Circuits |
| MO |
278000631 |
Male Terminal |
| MO |
278000735 |
Female Lock, 6 Circuits |
| MO |
515177192 |
Female Housing, 2 Circuits |
| NH |
710000992 |
Clip |
| NH |
710001164 |
Female Terminal |
| NH |
710001233 |
Seal |
| NV |
515176164 |
Male Terminal |
| NV |
515176621 |
Wire Seal |
| NV |
515176908 |
Female Housing |
| NV |
710000568 |
Housing |
| PA |
515176908 |
Female Housing |
| PA |
515176909 |
Terminal |
| PB |
515176909 |
Terminal |
| PB |
710001132 |
Housing |
| PE |
278001481 |
Female Terminal |
| PE |
278001482 |
Seal |
| PE |
515177192 |
Female Housing, 2 Circuits |
| PE |
710000643 |
Seal |
| PE |
710001133 |
Lock |
| PH |
409209900 |
Female Housing, 5 Circuits |
| PH |
710000925 |
Terminal |
| PH |
710001332 |
Seal Wire |
| R2 |
515175495 |
Female Housing, 3 Circuits |
| R2 |
561503100 |
FEMALE TERMINAL - Call your local BRP dealership This part replaces 409203300. |
| SA |
515175231 |
Female Terminal |
| SA |
710000568 |
Housing |
| SB |
515176164 |
Male Terminal |
| SB |
515176621 |
Wire Seal |
| SB |
515177192 |
Female Housing, 2 Circuits |
| SD |
409209600 |
Female Housing, 3 Circuits |
| SD |
710001164 |
Female Terminal |
| SD |
710001233 |
Seal |
| SM |
278001013 |
Wire Seal |
| SM |
278001014 |
Female Terminal |
| SM |
278002521 |
Female Terminal Housing, 3 Circuits |
| SM |
515176621 |
Wire Seal |
| SM |
710001340 |
Female Terminal |
| TP |
278000998 |
Female Terminal |
| TP |
278002520 |
Female Terminal Housing, 2 Circuits |
| TP |
415128501 |
Seal |
| TS |
278000998 |
Female Terminal |
| TS |
415128501 |
Seal |
| TS |
515175658 |
Female Housing, 2 Circuits |
