| Ref | Part Number | Description |
|---|
| 1 |
0392999 |
FUEL TANK ASSY |
| 2 |
0388933 |
CAP ASSY., Fuel |
| 5 |
0397832 |
FUEL LINE ASSY. This part replaces 0392064. |
| 12 |
0328491 |
HOPE, Long, 72" This part replaces 0321236. |
| 500 |
509001413 |
Thermostat Hose This part replaces 509001274. |
| 510 |
293650254 |
Oetiker Gear Clamp |
| 520 |
509000443 |
Aba Gear Clamp, 26-38 MM |
| 720 |
509000443 |
Aba Gear Clamp, 26-38 MM |
| 1190 |
219704421 |
Protector Tube 32 Mm 1000Mm Long |
| 1200 |
509001141 |
Hose |
| 1210 |
509000442 |
Oeticker Gear Clamp, 25.6-706R |
| 1220 |
509000968 |
Cooling Hose |
| 1230 |
293650046 |
Oetiker Clamp |
| 1240 |
293650046 |
Oetiker Clamp |
| 1250 |
509001041 |
Oetiker Clamp |
| 2000 |
861805527 |
Coolant Tank Kit |
| 2100 |
219704360 |
Hose 6 Mm 15000Mm Long |
| 2250 |
509000180 |
Radiator Pressure Cap |
| 8100 |
250000868 |
Torx Truss M6 X 50 |
| 8110 |
518331542 |
Coolant Tank Support |
| 8120 |
509001221 |
Coolant Tank Support |
| 8130 |
417127116 |
Swivel Abutment |
| 0173277 |
5008607 |
FLEXIBLE DE CARBURANT ET POIRE D'AMORÇAGE This part replaces 0173277. |
| 0174062 |
5008607 |
FLEXIBLE DE CARBURANT ET POIRE D'AMORÇAGE This part replaces 0174062. |
| 0320107 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
