08- Electric - Upper Section
Parts (44)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 5008623 | FUEL TANK This part replaces 0381015. |
| 2 | 0304888 | SCREW |
| 4 | 0310849 | HOUSING ASSY., Valve |
| 5 | 0312191 | SCREW, Indicator support |
| 6 | 0312190 | LENS |
| 7 | 0332505 | SEAL This part replaces 0312192. |
| 9 | 0398459 | FLOAT & INDICATOR This part replaces 0310845. |
| 10 | 0312193 | GASKET |
| 10 | 515178226 | Multifunction Gauge Full Size Color |
| 12 | 0125530 | GASKET, Housing to tank This part replaces 0310984. |
| 13 | 0377536 | FEUL TANK CAP ASSY |
| 16 | 0398409 | HOUSING This part replaces 0381016. |
| 20 | 0332488 | RING, Quad This part replaces 0307858. |
| 29 | 0306801 | CLAMP, Hose, small |
| 60 | 515178450 | Housing |
| 70 | 250000725 | Screw M4 X 16 |
| 600 | 515179240 | Terminal Dess One Wire |
| 610 | 278004274 | Specialized Nut |
| 620 | 515179476 | Grey, LYNX DESS Key |
| 800 | 515178645 | Heated Visor Wiring Harness |
| 810 | 572103300 | Cap |
| 1000 | 219400510 | USB Outlet |
| 1010 | 515178190 | Harness |
| 1040 | 515178153 | Extension Harness |
| 2200 | 707000995 | Pressure And Temperature Sensor |
| 2210 | 250000725 | Screw M4 X 16 |
| 2400 | 515178857 | Ignition Switch |
| 2401 | 515177952 | Clamp |
| 2420 | 250000671 | Torx Screw |
| 2470 | 415130141 | Sleeve |
| 2480 | 415130141 | Sleeve |
| 2600 | 515177931 | Emergency Stop Switch |
| 2610 | 515177310 | Emergency Stop Switch Support |
| 2620 | 250000263 | Torx Screw #8-18 |
| 3250 | 515178462 | Switch Rocker Hand Warmer |
| 3255 | 515178463 | Switch Rocker Headlignt |
| 5000a | 515177272 | Capacitor |
| 5003 | 250200140 | Washer |
| 5004 | 250200024 | Rubber Washer 5 mm |
| 5005 | 250000724 | Torx Screw M5 X 20 |
| 5010 | 515178430 | Rubber Stopper |
| 5020 | 515178159 | Module Support |
| 5025 | 207551634 | Hex. Flange Screw, Scotch Grip |
| 0386940 | 5008609 | FLEXIBLE DE CARBURANT ET POIRE D'AMORÇAGE This part replaces 0386940. |
