| Ref | Part Number | Description |
|---|
| 6 |
0324677 |
JOINT TORIQUE, mamelon, vidange inférieure |
| 8 |
0324678 |
JOINT TORIQUE Galet de came de papillon |
| 12 |
0032780 |
SCREW,Motor & reservoir to manifold |
| 28 |
0393988 |
MOTOR AND CABLE ASSY |
| 40 |
0360252 |
WASHER This part replaces 0306311. |
| 49 |
3*90006 |
CAP,O-ring & seal |
| 55 |
0321246 |
BUSHING, Shock absorber, lower |
| 70 |
0032171 |
RING BACKUP,End cap |
| 72 |
0321219 |
VIS, vis de fixation |
| 75 |
0321972 |
SCREW,Socket head |
| 83 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 85 |
0582093 |
LEAD ASSY This part replaces 0582092. |
| 88 |
0582878 |
INDICATOR GAUGE ASSY. This part replaces 0387758. |
| 93 |
0317000 |
COLLIER, câble |
| 94 |
0329289 |
JUNCTION BOX & COVER This part replaces 0328337. |
| 95 |
0582191 |
COLVER & TRANSFER ASSY |
| 96 |
0329289 |
JUNCTION BOX & COVER This part replaces 0328337. |
| 99 |
0512066 |
CLAMP |
| 100 |
0512639 |
BASE, Junction box This part replaces 0511870. |
| 105 |
0582182 |
CABLE ASSY, Battery |
| 106 |
0582723 |
LEAD & FUSE ASSY This part replaces 0582183. |
| 111 |
0582186 |
CONNECTOR & LEAD |
| 113 |
0582187 |
CABLE ASSY, Trim switch & guage |
| 119 |
0582188 |
CABLE ASSY TNT MOTOR |
| 123 |
0325698 |
CONNECTOR |
| 1075 |
0010780 |
TERMINAL |
| 0391037 |
0391037 |
HYDRAULIC ASSY |
| 0582192 |
0582192 |
JUNCTION BOX & COVER |
| 0582193 |
0582193 |
JUNCTION BOX & GAUGE ASSY |
