| Ref | Part Number | Description |
|---|
| 1 |
0312289 |
WASHER |
| 2 |
0306407 |
LOCCKWASHER,Cover latch |
| 3 |
0384104 |
PULLEY ASSEMBLY This part replaces 0383932. |
| 5 |
0306834 |
BOLT, Throttle lever retainer |
| 7 |
3852218 |
BRACKET, Oil cooler This part replaces 0383448. |
| 8 |
0306519 |
SCR,Coil clamp |
| 9 |
0308335 |
CLAMP, Coil |
| 10 |
0311415 |
SCREW, Cable clamp |
| 11 |
0314823 |
RETAINER, Cable con |
| 12 |
0306414 |
SCREW |
| 13 |
0310685 |
ABCHOR BLCOK, Trunnion |
| 14 |
0310687 |
DETENT SPRING, Anchor block |
| 15 |
0310688 |
SAPCER, Anchor block |
| 18 |
0311557 |
MANIFOLD BRACKET, Anchor block |
| 19 |
0310379 |
SCREW |
| 20 |
0310896 |
SCREW |
| 21 |
0980382 |
ADAPTER HOUSING This part replaces 0383159. |
| 23 |
0309614 |
DOWEL |
| 24 |
0160280 |
DRIVE SCREW |
| 25 |
0307001 |
L'WASHER, Stud c'case |
| 26 |
0303699 |
SCREW |
| 28 |
0379951 |
BRACKET & BRACE ASSY |
| 29 |
0380081 |
RUBBER MOUNT ASSEMBLY |
| 30 |
0330151 |
CLAMP, Harness to oil tank boss This part replaces 0309041. |
| 31 |
0981654 |
BALLAST RESISTOR This part replaces 0383433. |
| 32 |
0381169 |
BRACKET |
| 33 |
0306539 |
BOLT, Distributor |
| 34 |
0311391 |
SCR,Altnr to brkt |
| 35 |
0302479 |
VIS, démarreur vers bloc cylindres-carter This part replaces 0306416. |
| 37 |
0312309 |
BRACE, Alternator |
| 38 |
0383443 |
ALTERNAOR ASSY., Complete |
| 39 |
0311606 |
BELT |
| 41 |
0311056 |
SPACER |
| 42 |
0312271 |
GUARD, Ring gear |
| 43 |
3852435 |
HOSE Crankcase vent, 9" (229 mm) This part replaces 0311547. |
| 44 |
0308880 |
SCREW |
| 45 |
0304671 |
LOCKWASHER, Coupler to flywheel |
| 47 |
0203622 |
WASHER |
| 48 |
0311093 |
BRACKET |
| 49 |
0311094 |
GASKET |
| 50 |
0900289 |
FINISH, Washer, belt guard |
| 51 |
0900695 |
SCREW |
| 52 |
0311092 |
BRACKET, Starboard |
| 53 |
0315355 |
BRACKET, Upper |
| 54 |
0380491 |
BELT GUARD ASSY |
| 55 |
0311525 |
DECAL, Freezing temperature |
| 56 |
3852217 |
COIL ASSY. Ignition This part replaces 0383444. |
| 57 |
0550757 |
L'WASHER,Coil term |
| 59 |
0311111 |
LIFT BRACKET |
| 60 |
0306861 |
SCREW |
| 62 |
0312861 |
SCREW, Cable ground |
| 63 |
0314058 |
CONNECTOR |
| 65 |
0380451 |
FUEL LINE, Pump to tee |
| 66 |
0311611 |
FITTING |
| 67 |
0380450 |
FUEL LINE, Front carburetor |
| 68 |
0380449 |
FUEL LINE, Rear |
| 69 |
0310924 |
CLAMP, Main cable to adapter |
| 70 |
3852420 |
LOCKNUT, Throttle lever This part replaces 0900402. |
| 71 |
0329241 |
RONDELLE This part replaces 0306482. |
| 72 |
0311549 |
BAIL, Flame arrestor |
| 73 |
0380358 |
FLAME ARRESTOR |
| 74 |
0380493 |
BALL JOINT & LINK ASSEMBLY |
| 75 |
0132520 |
NUT |
| 76 |
0305238 |
BOW WASHER, Arm to bushing |
| 77 |
0204409 |
BUSHING, Pivot brkt |
| 78 |
0380452 |
THROTTLE SHAFT & ARM ASSEMBLY |
| 80 |
0306353 |
LKWASH,Brace to pump |
| 81 |
0311555 |
GASKET, carb to mainifold |
| 82 |
0381182 |
CARBURETOR ASSEMBLY |
| 83 |
0314254 |
CLAMP This part replaces 0310620. |
| 85 |
0306344 |
BALL SLEEVE |
| 86 |
0306345 |
NUT, Tube |
| 87 |
0311728 |
TUBE, Heat exchanger |
| 88 |
0311558 |
THROTTLE ARM |
| 89 |
0306128 |
SCREW, Arm |
| 92 |
0310897 |
SPACER |
| 93 |
0303899 |
NUT |
| 94 |
0309336 |
L'WASHER, Alternator to bracket |
| 97 |
0316093 |
TIE STRAP |
| 98 |
0206421 |
D WASHER |
| 0380492 |
0380492 |
BELT GUARD & BRACKET ASSEMBLY |
