TSK DP-G
Product ID:
TSKDPG
· Filter: TSKDPG
Sections (11)
Repair Kits
Miscellaneous, Repair Kits
Spare parts (165)
| Part # | Heading | Description | Category |
|---|---|---|---|
| 125017 | O-ring | ||
| 925050 | O-ring | ||
| 925053 | O-ring | ||
| 925064 | O-ring | ||
| 925093 | O-ring | ||
| 925095 | O-ring | ||
| 925256 | O-ring | ||
| 925259 | O-ring | ||
| 946438 | O-ring | ||
| 955974 | O-ring | ||
| 955981 | O-ring | ||
| 955982 | O-ring | ||
| 955985 | O-ring | ||
| 955989 | O-ring | ||
| 955991 | O-ring | ||
| 956000 | O-ring | ||
| 960214 | O-ring | ||
| 948211 | cable tie | ||
| 949666 | cable tie | ||
| 952630 | clamp | ||
| 952635 | clamp | ||
| 913158 | clevis pin | ||
| 947790 | flange screw | ||
| 948663 | flange screw | ||
| 965185 | flange screw | ||
| 946541 | hex. socket screw | ||
| 955780 | hexagon nut | ||
| 955806 | hexagon nut | ||
| 955298 | hexagon screw | ||
| 955512 | hexagon screw | ||
| 955516 | hexagon screw | ||
| 963545 | hexagon screw | ||
| 970945 | hexagon screw | ||
| 970951 | hexagon screw | ||
| 948294 | housing | ||
| 963108 | lock nut | ||
| 971089 | lock nut | ||
| 914169 | lubricating nipple | ||
| 969071 | round nut | ||
| 181620 | sealing ring | ||
| 942615 | sealing ring | ||
| 966207 | sealing ring | ||
| 977313 | sealing ring | ||
| 947904 | set screw | ||
| 17253 | split pin | ||
| 17276 | split pin | ||
| 949791 | split pin | ||
| 967707 | split pin | ||
| 941905 | spring washer | ||
| 941907 | spring washer | ||
| 941908 | spring washer | ||
| 965822 | terminal | ||
| 853706 | type plate | ||
| 941670 | washer | ||
| 955893 | washer | ||
| 976945 | washer | ||
| 853498 | anode kit | Cables and Fuses | |
| 853032 | cable block | Cables and Fuses | |
| 853066 | cable block | Cables and Fuses | |
| 856821 | cable kit | Cables and Fuses | |
| 853521 | terminal | Cables and Fuses | |
| 872448 | wiring harness | Cables and Fuses | |
| 828250 | Water resistant grease | Chemical Products | |
| 861742 | hose | Cooling System | |
| 872338 | hose connection | Cooling System | |
| 872334 | nipple | Cooling System | |
| 861090 | tube | Cooling System | |
| 839091 | protecting hose | Engine Controls | |
| 860396 | exhaust hose | Inlet and Exhaust System | |
| 3581130 | exhaust pipe | Inlet and Exhaust System | |
| 872238 | seal flange kit | Inlet and Exhaust System | |
| 858643 | Front ring for instruments | Instruments | |
| 3588768 | Anode for Aquamatic sterndrive - single prop drive 290, SP & duo prop drive 290, DP, DPH, DPI, DPR - Transom shield | Marine Propulsion | |
| 3588770 | Anode for Aquamatic sterndrive - single prop drive 290, SP & duo prop drive 290, DP, DPH, DPI, DPR - Transom shield | Marine Propulsion | |
| 852835 | Aquamatic sterndrive - single prop drive 290, SP & duo prop drive 290, DP - Transom shield | Marine Propulsion | |
| 872498 | Drive Trim Instruments (Drive trim position instrument, 52 mm) | Marine Propulsion | |
| 3852045 | O-ring | Marine Propulsion | |
| 3855081 | O-ring | Marine Propulsion | |
| 3861573 | O-ring | Marine Propulsion | |
| 3861578 | O-ring | Marine Propulsion | |
| 873232 | O-ring | Marine Propulsion | |
| 3855650 | Power Trim control unit | Marine Propulsion | |
| 23307656 | Service kits for Aquamatic Sterndrives | Marine Propulsion | |
| 872096 | bearing bushing | Marine Propulsion | |
| 876294 | bellows kit | Marine Propulsion | |
| 854438 | bracket | Marine Propulsion | |
| 851430 | bushing | Marine Propulsion | |
| 853223 | bushing | Marine Propulsion | |
| 876278 | bushing kit | Marine Propulsion | |
| 876279 | bushing kit | Marine Propulsion | |
| 3861572 | cap | Marine Propulsion | |
| 854628 | clamp | Marine Propulsion | |
| 872126 | clevis pin | Marine Propulsion | |
| 814473 | closure | Marine Propulsion | |
| 3861577 | connector | Marine Propulsion | |
| 3860881 | cylinder | Marine Propulsion | |
| 804269 | drive screw | Marine Propulsion | |
| 852984 | driving wheel | Marine Propulsion | |
| 3861576 | electric motor | Marine Propulsion | |
| 853060 | flange screw | Marine Propulsion | |
| 3857147 | fork | Marine Propulsion | |
| 804344 | gasket | Marine Propulsion | |
| 814168 | gasket | Marine Propulsion | |
| 832669 | gasket | Marine Propulsion | |
| 897682 | gasket | Marine Propulsion | |
| 897745 | gasket | Marine Propulsion | |
| 876266 | gasket kit | Marine Propulsion | |
| 876639 | gasket kit | Marine Propulsion | |
| 3856815 | gear segment | Marine Propulsion | |
| 872752 | hose connection | Marine Propulsion | |
| 876632 | hose kit | Marine Propulsion | |
| 873228 | hydraulic hose | Marine Propulsion | |
| 873229 | hydraulic hose | Marine Propulsion | |
| 872207 | nipple | Marine Propulsion | |
| 852212 | nut | Marine Propulsion | |
| 852879 | plug | Marine Propulsion | |
| 853215 | plug | Marine Propulsion | |
| 3860880 | pump | Marine Propulsion | |
| 3861570 | reservoir | Marine Propulsion | |
| 853760 | rivet nut | Marine Propulsion | |
| 3861574 | screw | Marine Propulsion | |
| 853759 | screw | Marine Propulsion | |
| 814356 | seal | Marine Propulsion | |
| 851407 | sealing ring | Marine Propulsion | |
| 853868 | sealing ring | Marine Propulsion | |
| 853871 | sealing ring | Marine Propulsion | |
| 872755 | sealing ring | Marine Propulsion | |
| 852868 | sealing strip | Marine Propulsion | |
| 873531 | sensor | Marine Propulsion | |
| 854625 | set | Marine Propulsion | |
| 3856809 | shield | Marine Propulsion | |
| 872382 | spindle | Marine Propulsion | |
| 872493 | spindle | Marine Propulsion | |
| 806624 | striker plate | Marine Propulsion | |
| 873316 | stud | Marine Propulsion | |
| 3862171 | support plate | Marine Propulsion | |
| 854696 | tube | Marine Propulsion | |
| 854697 | tube | Marine Propulsion | |
| 852866 | washer | Marine Propulsion | |
| 853059 | washer | Marine Propulsion | |
| 872403 | washer | Marine Propulsion | |
| 875821 | zinc ring kit | Marine Propulsion | |
| 1324492 | relay | Other Electrical Equipment | |
| 854357 | relay | Other Electrical Equipment | |
| 872300 | relay | Other Electrical Equipment | |
| 961669 | Rubber hoses | Parts for Fastening, Spacing, Locking and Support, Stock Shape Materials | |
| 853548 | hose clamp | Parts for Fastening, Spacing, Locking and Support, Stock Shape Materials | |
| 982694 | hose clamp | Parts for Fastening, Spacing, Locking and Support, Stock Shape Materials | |
| 828894 | adjusting bar | Steering | |
| 853039 | bracket | Steering | |
| 853048 | bushing | Steering | |
| 854704 | bushing | Steering | |
| 854705 | bushing | Steering | |
| 872700 | bushing | Steering | |
| 872490 | clevis pin | Steering | |
| 1140020 | deflection limiter | Steering | |
| 1140610 | link rod kit | Steering | |
| 1140021 | lock ring | Steering | |
| 853160 | lock washer | Steering | |
| 872103 | pivot pin | Steering | |
| 872355 | spacer sleeve | Steering | |
| 872722 | steering arm | Steering | |
| 872311 | tab washer | Steering | |
| 828892 | tube | Steering | |
| 828893 | tube | Steering |
