Home / Volvo Penta / K25

K25

Product ID: K25 · Filter: K25

Sections (4)

Control Mechanism Reverse Bucket
Engine Controls
Bearing House
Marine Propulsion
Water Jet
Marine Propulsion
Water Jet
Marine Propulsion

Spare parts (223)

Part #HeadingDescriptionCategory
925093 O-ring
925261 O-ring
3829518 T-nipple
976930 gasket
946541 hex. socket screw
946543 hex. socket screw
959286 hex. socket screw
963678 hex. socket screw
963697 hex. socket screw
963701 hex. socket screw
963706 hex. socket screw
963728 hex. socket screw
963761 hexagon nut
963556 hexagon screw
963567 hexagon screw
963568 hexagon screw
963570 hexagon screw
963580 hexagon screw
963590 hexagon screw
963629 hexagon screw
963630 hexagon screw
971018 hexagon screw
971019 hexagon screw
971021 hexagon screw
971022 hexagon screw
971024 hexagon screw
971029 hexagon screw
971046 hexagon screw
971048 hexagon screw
982523 hexagon screw
982525 hexagon screw
984367 hexagon screw
984914 hexagon screw
966171 lock nut
982529 lock nut
907026 lock washer
3829477 nipple
3829961 nipple
3829962 nipple
3829485 pressure hose
3829478 return hose
906636 round nut
982498 screw
969898 six point socket screw
969912 six point socket screw
982528 six point socket screw
941670 washer
942551 washer
943111 washer
943194 washer
873938 extension cable Cables and Fuses
873939 extension cable Cables and Fuses
873940 extension cable Cables and Fuses
873941 extension cable Cables and Fuses
873942 extension cable Cables and Fuses
874061 extension cable Cables and Fuses
874167 wiring harness Cables and Fuses
873983 control panel Instruments
874065 control panel Instruments
874172 control panel Instruments
874173 control panel Instruments
3588768 Anode for Aquamatic sterndrive - single prop drive 290, SP & duo prop drive 290, DP, DPH, DPI, DPR - Transom shield Marine Propulsion
3588770 Anode for Aquamatic sterndrive - single prop drive 290, SP & duo prop drive 290, DP, DPH, DPI, DPR - Transom shield Marine Propulsion
852835 Aquamatic sterndrive - single prop drive 290, SP & duo prop drive 290, DP - Transom shield Marine Propulsion
3828057 O-ring Marine Propulsion
3829948 O-ring Marine Propulsion
3828321 adapter Marine Propulsion
3829309 adapter Marine Propulsion
877130 anode Marine Propulsion
877297 anode Marine Propulsion
877298 anode Marine Propulsion
877144 anode kit Marine Propulsion
877148 anode kit Marine Propulsion
877150 anode kit Marine Propulsion
877151 anode kit Marine Propulsion
877153 anode kit Marine Propulsion
877154 anode kit Marine Propulsion
877267 anode kit Marine Propulsion
877296 anode kit Marine Propulsion
877299 anode kit Marine Propulsion
877300 anode kit Marine Propulsion
877301 anode kit Marine Propulsion
877312 anode kit Marine Propulsion
877313 anode kit Marine Propulsion
877314 anode kit Marine Propulsion
877137 axle Marine Propulsion
3828320 axle shaft Marine Propulsion
3828291 bearing Marine Propulsion
3828304 bearing Marine Propulsion
3828064 bearing bushing Marine Propulsion
3828068 bearing bushing Marine Propulsion
3582859 bearing housing Marine Propulsion
3830615 bearing housing Marine Propulsion
3828284 bucket Marine Propulsion
877129 bushing Marine Propulsion
3829451 by-pass unit Marine Propulsion
3828191 control system Marine Propulsion
3830097 control system Marine Propulsion
3831019 control system Marine Propulsion
3828287 cylinder Marine Propulsion
874218 electronic unit Marine Propulsion
3828054 eye bolt Marine Propulsion
3828203 filler cap Marine Propulsion
3828204 filter Marine Propulsion
3829435 filter Marine Propulsion
3828464 grease nipple Marine Propulsion
877149 hose kit Marine Propulsion
3828333 hydraulic valve Marine Propulsion
3828453 hydraulic valve Marine Propulsion
3829294 hydraulic valve Marine Propulsion
3829406 hydraulic valve Marine Propulsion
877127 impeller Marine Propulsion
877135 impeller Marine Propulsion
3828589 insulating washer Marine Propulsion
3829765 insulating washer Marine Propulsion
3828072 lifting eye Marine Propulsion
3828059 lock nut Marine Propulsion
3828292 lock nut Marine Propulsion
3828274 lock washer Marine Propulsion
877125 overhaul kit Marine Propulsion
877146 overhaul kit Marine Propulsion
877147 overhaul kit Marine Propulsion
877286 overhaul kit Marine Propulsion
877307 overhaul kit Marine Propulsion
3829751 plug Marine Propulsion
3829910 plug Marine Propulsion
3829224 reduction nipple Marine Propulsion
877132 reverse gear Marine Propulsion
877133 reverse gear Marine Propulsion
877138 reverse gear Marine Propulsion
877128 rubber bearing Marine Propulsion
3830629 screw Marine Propulsion
3830632 screw Marine Propulsion
3828297 seal Marine Propulsion
3828302 seal Marine Propulsion
3828303 seal Marine Propulsion
3828305 seal Marine Propulsion
3830087 seal Marine Propulsion
877285 seal Marine Propulsion
877145 sealing kit Marine Propulsion
877159 set Marine Propulsion
877263 set Marine Propulsion
877264 set Marine Propulsion
877265 set Marine Propulsion
877266 set Marine Propulsion
877270 set Marine Propulsion
877276 set Marine Propulsion
877277 set Marine Propulsion
877294 set Marine Propulsion
877295 set Marine Propulsion
877308 set Marine Propulsion
877309 set Marine Propulsion
877310 set Marine Propulsion
877311 set Marine Propulsion
877317 set Marine Propulsion
877323 set Marine Propulsion
877324 set Marine Propulsion
3830838 shaft Marine Propulsion
3830839 shaft Marine Propulsion
3830840 shaft Marine Propulsion
3830841 shaft Marine Propulsion
877293 shim Marine Propulsion
3829776 sleeve Marine Propulsion
3828294 spacer Marine Propulsion
3828069 spacer sleeve Marine Propulsion
3828289 spacer washer Marine Propulsion
3829768 spacer washer Marine Propulsion
877155 spare parts kit Marine Propulsion
877156 spare parts kit Marine Propulsion
877157 spare parts kit Marine Propulsion
877158 spare parts kit Marine Propulsion
877160 spare parts kit Marine Propulsion
877161 spare parts kit Marine Propulsion
877162 spare parts kit Marine Propulsion
877163 spare parts kit Marine Propulsion
877164 spare parts kit Marine Propulsion
877166 spare parts kit Marine Propulsion
877169 spare parts kit Marine Propulsion
877268 spare parts kit Marine Propulsion
877269 spare parts kit Marine Propulsion
877271 spare parts kit Marine Propulsion
877272 spare parts kit Marine Propulsion
877273 spare parts kit Marine Propulsion
877274 spare parts kit Marine Propulsion
877275 spare parts kit Marine Propulsion
877278 spare parts kit Marine Propulsion
877279 spare parts kit Marine Propulsion
877280 spare parts kit Marine Propulsion
877281 spare parts kit Marine Propulsion
877282 spare parts kit Marine Propulsion
877283 spare parts kit Marine Propulsion
877284 spare parts kit Marine Propulsion
877315 spare parts kit Marine Propulsion
877316 spare parts kit Marine Propulsion
877318 spare parts kit Marine Propulsion
877319 spare parts kit Marine Propulsion
877320 spare parts kit Marine Propulsion
877321 spare parts kit Marine Propulsion
877322 spare parts kit Marine Propulsion
877325 spare parts kit Marine Propulsion
877326 spare parts kit Marine Propulsion
877327 spare parts kit Marine Propulsion
877328 spare parts kit Marine Propulsion
877329 spare parts kit Marine Propulsion
877330 spare parts kit Marine Propulsion
877331 spare parts kit Marine Propulsion
3829749 split pin Marine Propulsion
877139 spray nozzle Marine Propulsion
877141 spray nozzle Marine Propulsion
877142 spray nozzle Marine Propulsion
877143 spray nozzle Marine Propulsion
877136 stator Marine Propulsion
3828281 stator housing Marine Propulsion
3828285 stay Marine Propulsion
3828273 steering cylinder Marine Propulsion
1140580 steering pump Marine Propulsion
3828446 steering pump Marine Propulsion
3828278 steering rod Marine Propulsion
877131 steering rod Marine Propulsion
3829409 synchronizing unit Marine Propulsion
877171 valve kit Marine Propulsion
3828065 zinc electrode Marine Propulsion
3828295 zinc electrode Marine Propulsion
