DPX-S1
Product ID:
DPXS1
· Filter: DPXS1
Sections (11)
Spare parts (242)
| Part # | Heading | Description | Category |
|---|---|---|---|
| 925052 | O-ring | ||
| 925064 | O-ring | ||
| 925095 | O-ring | ||
| 925256 | O-ring | ||
| 925259 | O-ring | ||
| 941820 | O-ring | ||
| 946438 | O-ring | ||
| 955974 | O-ring | ||
| 955981 | O-ring | ||
| 955989 | O-ring | ||
| 979254 | O-ring | ||
| 183374 | ball bearing | ||
| 942871 | clevis pin | ||
| 872342 | decal | ||
| 872343 | decal | ||
| 872344 | decal | ||
| 945444 | flange screw | ||
| 946329 | flange screw | ||
| 947790 | flange screw | ||
| 941807 | hex. socket screw | ||
| 941808 | hex. socket screw | ||
| 956591 | hex. socket screw | ||
| 959427 | hex. socket screw | ||
| 959448 | hex. socket screw | ||
| 959456 | hex. socket screw | ||
| 959457 | hex. socket screw | ||
| 959461 | hex. socket screw | ||
| 963684 | hex. socket screw | ||
| 940157 | hexagon nut | ||
| 940160 | hexagon screw | ||
| 940168 | hexagon screw | ||
| 940169 | hexagon screw | ||
| 945996 | hexagon screw | ||
| 955297 | hexagon screw | ||
| 955516 | hexagon screw | ||
| 970945 | hexagon screw | ||
| 970947 | hexagon screw | ||
| 184683 | inner ring | ||
| 853830 | insert | ||
| 941885 | lock nut | ||
| 183272 | needle roller bearing | ||
| 183859 | needle roller bushing | ||
| 184654 | needle roller bushing | ||
| 832939 | nut | ||
| 11041 | roller bearing | ||
| 11044 | roller bearing | ||
| 11072 | roller bearing | ||
| 183247 | roller bearing | ||
| 183647 | roller bearing | ||
| 184691 | roller bearing | ||
| 184765 | roller bearing | ||
| 853949 | roller bearing | ||
| 969071 | round nut | ||
| 969072 | round nut | ||
| 958860 | sealing ring | ||
| 191834 | shim | ||
| 191835 | shim | ||
| 191837 | shim | ||
| 42980 | shim | ||
| 42981 | shim | ||
| 941823 | shim | ||
| 941824 | shim | ||
| 941825 | shim | ||
| 941826 | shim | ||
| 941827 | shim | ||
| 941832 | shim | ||
| 941833 | shim | ||
| 943869 | shim | ||
| 943870 | shim | ||
| 944522 | shim | ||
| 946179 | shim | ||
| 948230 | shim | ||
| 967351 | shim | ||
| 967352 | shim | ||
| 854144 | sign | ||
| 914465 | snap ring | ||
| 914470 | snap ring | ||
| 914533 | snap ring | ||
| 914538 | snap ring | ||
| 951078 | snap ring | ||
| 17253 | split pin | ||
| 17276 | split pin | ||
| 951924 | spring pin | ||
| 941907 | spring washer | ||
| 941909 | spring washer | ||
| 977241 | stud | ||
| 968950 | support washer | ||
| 853706 | type plate | ||
| 940191 | washer | ||
| 947541 | washer | ||
| 955893 | washer | ||
| 955897 | washer | ||
| 976945 | washer | ||
| 861742 | hose | Cooling System | |
| 872338 | hose connection | Cooling System | |
| 872334 | nipple | Cooling System | |
| 861090 | tube | Cooling System | |
| 804312 | cube | Engine Controls | |
| 860396 | exhaust hose | Inlet and Exhaust System | |
| 3581130 | exhaust pipe | Inlet and Exhaust System | |
| 872238 | seal flange kit | Inlet and Exhaust System | |
| 876638 | Anode for Aquamatic sterndrive - duo prop drive DPX - Spray plate | Marine Propulsion | |
| 24007660 | Anode for Aquamatic sterndrive - duo prop drive DPX - intermediate house | Marine Propulsion | |
| 3863480 | Anode for Aquamatic sterndrive - duo prop drive DPX - intermediate house | Marine Propulsion | |
| 873232 | O-ring | Marine Propulsion | |
| 3868638 | aquamatic drive | Marine Propulsion | |
| 3868639 | aquamatic drive | Marine Propulsion | |
| 853876 | attaching plate | Marine Propulsion | |
| 853878 | attaching plate | Marine Propulsion | |
| 853850 | axle shaft | Marine Propulsion | |
| 853944 | axle shaft | Marine Propulsion | |
| 3852389 | bearing | Marine Propulsion | |
| 3852390 | bearing | Marine Propulsion | |
| 872756 | bearing bushing | Marine Propulsion | |
| 3855784 | bearing housing | Marine Propulsion | |
| 872136 | bearing housing | Marine Propulsion | |
| 872993 | bearing housing | Marine Propulsion | |
| 876294 | bellows kit | Marine Propulsion | |
| 876631 | bellows kit | Marine Propulsion | |
| 838935 | bracket | Marine Propulsion | |
| 838936 | bracket | Marine Propulsion | |
| 853829 | bushing | Marine Propulsion | |
| 876507 | bushing kit | Marine Propulsion | |
| 872969 | cap | Marine Propulsion | |
| 897387 | clamping ring | Marine Propulsion | |
| 3851604 | clevis pin | Marine Propulsion | |
| 872126 | clevis pin | Marine Propulsion | |
| 814473 | closure | Marine Propulsion | |
| 853977 | clutch | Marine Propulsion | |
| 853978 | clutch | Marine Propulsion | |
| 838422 | clutch flange | Marine Propulsion | |
| 872293 | countershaft | Marine Propulsion | |
| 872957 | cover | Marine Propulsion | |
| 814603 | dog | Marine Propulsion | |
| 804269 | drive screw | Marine Propulsion | |
| 3868021 | drive unit | Marine Propulsion | |
| 3868023 | drive unit | Marine Propulsion | |
| 897816 | eccentric piston | Marine Propulsion | |
| 873345 | extension kit | Marine Propulsion | |
| 854616 | fork | Marine Propulsion | |
| 854617 | fork | Marine Propulsion | |
| 872539 | fork | Marine Propulsion | |
| 3851712 | förlängn.sats | Marine Propulsion | |
| 832669 | gasket | Marine Propulsion | |
| 897682 | gasket | Marine Propulsion | |
| 872133 | gear | Marine Propulsion | |
| 872146 | gear | Marine Propulsion | |
| 872297 | gear | Marine Propulsion | |
| 872398 | gear | Marine Propulsion | |
| 872404 | gear | Marine Propulsion | |
| 872990 | gear | Marine Propulsion | |
| 873310 | gear | Marine Propulsion | |
| 873313 | gear | Marine Propulsion | |
| 872134 | gear housing | Marine Propulsion | |
| 897711 | hexagon screw | Marine Propulsion | |
| 814643 | hollow screw | Marine Propulsion | |
| 872752 | hose connection | Marine Propulsion | |
| 876632 | hose kit | Marine Propulsion | |
| 872176 | hub | Marine Propulsion | |
| 872177 | hub | Marine Propulsion | |
| 3855772 | intermediate housing | Marine Propulsion | |
| 872921 | intermediate housing | Marine Propulsion | |
| 24383 | lock ring | Marine Propulsion | |
| 872174 | lock screw | Marine Propulsion | |
| 3852295 | locking clip | Marine Propulsion | |
| 854229 | mutter 1 | Marine Propulsion | |
| 854230 | mutter 2 | Marine Propulsion | |
| 3852375 | nut | Marine Propulsion | |
| 852212 | nut | Marine Propulsion | |
| 854228 | nut | Marine Propulsion | |
| 839351 | oil dipstick | Marine Propulsion | |
| 897823 | oil pipe | Marine Propulsion | |
| 814482 | oil strainer | Marine Propulsion | |
| 872922 | pin | Marine Propulsion | |
| 804262 | plug | Marine Propulsion | |
| 814179 | plug | Marine Propulsion | |
| 853484 | pretensioning sleeve | Marine Propulsion | |
| 3860011 | propeller | Marine Propulsion | |
| 3860012 | propeller | Marine Propulsion | |
| 3860013 | propeller | Marine Propulsion | |
| 3860065 | propeller | Marine Propulsion | |
| 3860066 | propeller | Marine Propulsion | |
| 3860067 | propeller | Marine Propulsion | |
| 872422 | propeller | Marine Propulsion | |
| 872423 | propeller | Marine Propulsion | |
| 872424 | propeller | Marine Propulsion | |
| 3851335 | propeller nut | Marine Propulsion | |
| 872179 | propeller nut | Marine Propulsion | |
| 872393 | propeller shaft | Marine Propulsion | |
| 872759 | protecting casing | Marine Propulsion | |
| 853838 | protecting screen | Marine Propulsion | |
| 853874 | protecting screen | Marine Propulsion | |
| 873534 | retainer | Marine Propulsion | |
| 858464 | rubber ring | Marine Propulsion | |
| 853951 | screw | Marine Propulsion | |
| 853952 | screw | Marine Propulsion | |
| 854201 | screw | Marine Propulsion | |
| 839253 | sealing ring | Marine Propulsion | |
| 851407 | sealing ring | Marine Propulsion | |
| 853871 | sealing ring | Marine Propulsion | |
| 872755 | sealing ring | Marine Propulsion | |
| 873291 | sealing ring | Marine Propulsion | |
| 3855786 | selector unit | Marine Propulsion | |
| 3852292 | shaft | Marine Propulsion | |
| 897447 | shaft | Marine Propulsion | |
| 853034 | shim | Marine Propulsion | |
| 853035 | shim | Marine Propulsion | |
| 853036 | shim | Marine Propulsion | |
| 872986 | sleeve | Marine Propulsion | |
| 3855783 | sliding sleeve | Marine Propulsion | |
| 873312 | sliding sleeve | Marine Propulsion | |
| 854192 | spacer ring | Marine Propulsion | |
| 853834 | spacer sleeve | Marine Propulsion | |
| 854619 | spider | Marine Propulsion | |
| 853841 | spindle | Marine Propulsion | |
| 3852268 | splined sleeve | Marine Propulsion | |
| 854684 | splined sleeve | Marine Propulsion | |
| 3852296 | spring | Marine Propulsion | |
| 814184 | spring | Marine Propulsion | |
| 872753 | steering knuckle | Marine Propulsion | |
| 873347 | stud | Marine Propulsion | |
| 872172 | thrust ring | Marine Propulsion | |
| 872754 | thrust washer | Marine Propulsion | |
| 854615 | universal joint | Marine Propulsion | |
| 854618 | universal joint | Marine Propulsion | |
| 3856203 | upper gear | Marine Propulsion | |
| 832675 | washer | Marine Propulsion | |
| 853026 | washer | Marine Propulsion | |
| 853095 | washer | Marine Propulsion | |
| 854126 | washer | Marine Propulsion | |
| 872403 | washer | Marine Propulsion | |
| 873352 | washer | Marine Propulsion | |
| 897511 | washer | Marine Propulsion | |
| 872977 | yoke | Marine Propulsion | |
| 873395 | zinc electrode | Marine Propulsion | |
| 22274888 | Rubber exhaust hoses | Parts for Fastening, Spacing, Locking and Support, Stock Shape Materials | |
| 961669 | Rubber hoses | Parts for Fastening, Spacing, Locking and Support, Stock Shape Materials | |
| 853012 | hose clamp | Parts for Fastening, Spacing, Locking and Support, Stock Shape Materials | |
| 853013 | hose clamp | Parts for Fastening, Spacing, Locking and Support, Stock Shape Materials | |
| 853548 | hose clamp | Parts for Fastening, Spacing, Locking and Support, Stock Shape Materials | |
| 872531 | hose clamp | Parts for Fastening, Spacing, Locking and Support, Stock Shape Materials | |
| 982694 | hose clamp | Parts for Fastening, Spacing, Locking and Support, Stock Shape Materials |
